2-Port VGA Video Switch
Model VS291-AT-GEAN 4710423771628
37 specifications
- Weight220 g
- ColourSilver
- Video port typeVGA
- MaterialMetal, Plastic
- Power consumption (typical)0.82 W
- Width65.2 mm
Overview
- Weight
- 220 g
- Colour
- Silver
- Video port type
- VGA
- Material
- Metal, Plastic
- Power consumption (typical)
- 0.82 W
- Width
- 65.2 mm
- Brand
- ATEN
- Category
- Video Switch
- Model
- VS291-AT-G
- Part number
- VS291-AT-G
- EAN / UPC
- 4710423771628
- Also known as
- ATEN 2-Port VGA Video Switch
Specifications
37 specifications in 8 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 3 |
| VGA (D-Sub) input ports | 2 |
| VGA (D-Sub) output ports | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal, Plastic |
| Product colour | Silver |
| Bandwidth | 150 MHz |
| Input impedance | 75 Ω |
| LED indicators | Yes |
| Maximum operating distance | 10 m |
| Maximum refresh rate | 60 Hz |
| Maximum resolution | 1920 x 1440 pixels |
| Output impedance | 75 Ω |
| Supported graphics resolutions | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1600 x 1200 (UXGA), 1920 x 1440 |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 0.82 W |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 65.2 mm |
| Depth | 120 mm |
| Height | 44 mm |
| Weight | 220 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 360 g |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| AC adapter included | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 315 mm |
| Master (outer) case length | 490 mm |
| Master (outer) case height | 338 mm |
| Master (outer) case gross weight | 7.9 kg |
| Master (outer) case net weight | 4.4 kg |
| Products per master (outer) case | 20 pc(s) |
