ATEN VM3404H-AT-E video switch HDMI
Model VM3404H-AT-E
25 specifications
- Weight5.62 kg
- ColourBlack
- Video port typeHDMI
- MaterialMetal
- AC adapter input voltage100 - 240 V
- Width382.3 mm
Overview
- Weight
- 5.62 kg
- Colour
- Black
- Video port type
- HDMI
- Material
- Metal
- AC adapter input voltage
- 100 - 240 V
- Width
- 382.3 mm
- Brand
- ATEN
- Category
- Video Switch
- Model
- VM3404H-AT-E
- Part number
- VM3404H-AT-E
- Also known as
- ATEN VM3404H-AT-E video switch HDMI
Specifications
25 specifications in 6 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI ports quantity | 8 |
| HDMI in | 4 |
| Number of HDMI outputs | 4 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 4 |
| RS-232 ports | 1 |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| 3D | Yes |
| HDCP | Yes |
| Maximum operating distance | 70 m |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160 |
Power
| Specification | Value |
|---|---|
| AC adapter input voltage | 100 - 240 V |
| AC adapter frequency | 50/60 Hz |
| AC adapter input current | 1 A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 382.3 mm |
| Depth | 432.4 mm |
| Height | 44 mm |
| Weight | 5.62 kg |
Packaging content
| Specification | Value |
|---|---|
| Quantity per pack | 1 pc(s) |
| Cables included | AC |
| Mounting brackets included | Yes |
| User guide | Yes |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
