VM0404 video switch HDMI
Model VM0404Part no. VM0404-AT-GEAN 672792100307
28 specifications
- Weight870 g
- ColourBlack
- Video port typeHDMI
- MaterialMetal
- Power consumption (typical)2.7 W
- Width260 mm
Overview
- Weight
- 870 g
- Colour
- Black
- Video port type
- HDMI
- Material
- Metal
- Power consumption (typical)
- 2.7 W
- Width
- 260 mm
- Brand
- ATEN
- Category
- Video Switch
- Model
- VM0404
- Part numbers
- VM0404-AT-G, VM0404
- EAN / UPC
- 672792100307, 672792004353, 6727920043538, 4710423773844
- Also known as
- ATEN VM0404 video switch HDMI
Specifications
28 specifications in 6 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | HDMI |
| HDMI ports quantity | 8 |
| VGA (D-Sub) ports quantity | 8 |
| RS-232 ports | 1 |
| Video in | 4 |
| Video out | 4 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| Bandwidth | 300 MHz |
| Built-in speaker(s) | No |
| HD type | Full HD |
| LED indicators | Yes |
| Maximum operating distance | 30 m |
| Rack capacity | 1U |
| Rack mounting | Yes |
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
| Supported video modes | 1080p |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.7 W |
| Power requirements | 5.3VDC |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 260 mm |
| Depth | 76.1 mm |
| Height | 44 mm |
| Weight | 870 g |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
