VC1080
Model VC1080EAN 672792003288
17 specifications
- Weight1.48 kg
- ColourBlack
- Video port typeVGA
- MaterialMetal
- Operating temperature (T-T)0 - 50 °C
Overview
- Weight
- 1.48 kg
- Colour
- Black
- Video port type
- VGA
- Material
- Metal
- Operating temperature (T-T)
- 0 - 50 °C
- Brand
- ATEN
- Category
- Video Switch
- Model
- VC1080
- Part number
- VC1080
- EAN / UPC
- 672792003288, 4710423777903, 6727920032884
- Also known as
- ATEN AT-VC1080
Specifications
17 specifications in 5 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Video port type | VGA |
| VGA (D-Sub) ports quantity | 2 |
| Composite video in | 2 |
| Component video (YPbPr/YCbCr) in | 6 |
| RS-232 ports | 1 |
| DC-in jack | Yes |
Features
| Specification | Value |
|---|---|
| Material | Metal |
| Product colour | Black |
| LED indicators | Yes |
| Supported graphics resolutions | 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Supported video modes | 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.48 kg |
| Dimensions (WxDxH) | 161.3 x 335 x 44 mm |
Packaging content
| Specification | Value |
|---|---|
| Cables included | IR |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
