V11H756020 smartglasses
1.44 GHz Bluetooth Wi-Fi Built-in camera
Model V11H756020
34 specifications
- ProcessorIntel Atom® x5
- Memory16 GB
- OSMoverio OS
- Weight69 g
- Processor frequency1.44 GHz
- Built-in cameraYes
Overview
- Processor
- Intel Atom® x5
- Memory
- 16 GB
- OS
- Moverio OS
- Weight
- 69 g
- Processor frequency
- 1.44 GHz
- Built-in camera
- Yes
- Brand
- Epson
- Category
- Smartglass
- Model
- V11H756020
- Part number
- V11H756020
- Also known as
- Epson V11H756020 smartglasses 1.44 GHz Bluetooth Wi-Fi Built-in camera
Specifications
34 specifications in 7 groups
Features
| Specification | Value |
|---|---|
| Processor frequency | 1.44 GHz |
| Processor manufacturer | Intel |
| Processor family | Intel Atom® x5 |
| Processor cores | 4 |
| Internal memory | 16 GB |
| Driving method | Monocrystalline silicon active matrix |
| Accelerometer | Yes |
| Number of accelerometer axis | 3 |
| Gyroscope | Yes |
| Number of gyroscope axis | 3 |
| Magnetometer | No |
| Barometer | No |
| GLONASS | No |
| GPS (satellite) | Yes |
| Operating system installed | Moverio OS |
Camera
| Specification | Value |
|---|---|
| Built-in camera | Yes |
| Megapixel (approx.) | 5 MP |
Network
| Specification | Value |
|---|---|
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
| Bluetooth profiles | A2DP, AVRCP, HSP, OPP, SSP |
| Wi-Fi | Yes |
| Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11a, 802.11b, 802.11g |
Power
| Specification | Value |
|---|---|
| AC adapter input voltage | 100 - 240 V |
| Battery life (max) | 6 h |
| USB charging | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 178.1 mm |
| Height | 24.9 mm |
| Weight | 69 g |
| Width | 191 mm |
| Control unit dimensions (W x D x H) | 55.88 x 116.078 x 23.114 mm |
| Control unit weight | 129 g |
Ports & interfaces
| Specification | Value |
|---|---|
| Micro-USB 2.0 ports quantity | 1 |
