Zyxel XGS2210-52 Managed L2 Gigabit Ethernet (10/100/1000) 1U Black

XGS2210-52 Managed L2 Gigabit Ethernet (10/100/1000) 1U Black

Model XGS2210-52Part no. XGS2210-52-EU0101FEAN 4718937587902

71 specifications

Noise44.15 dB
Type1U
Weight3.86 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity48

See all specifications

Overview

Noise: 44.15 dB
Type: 1U
Weight: 3.86 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 48

Brand: Zyxel
Category: Network Switch
Model: XGS2210-52
Part numbers: XGS2210-52-EU0101F, 3182, XGS2210-52-GB0101F
EAN / UPC: 4718937587902, 4718937588206
Also known as: Zyxel XGS2210-52 Managed L2 Gigabit Ethernet (10/100/1000) 1U Black

Specifications

71 specifications in 16 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
Traffic shaping	Yes
System event log	Yes
MIB support	RFC 1066, RFC 1213, RFC 1493, RFC 1643, RFC 1757, RFC 2011, RFC 2233, RFC 2358, RFC 2674, RFC 2819, RFC 2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292, RFC 4293

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP+ module slots quantity	4

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Yes
Port mirroring	Yes
IP routing	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
MAC address auto-learning supported	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	176 Gbit/s
Throughput	130.9 Mpps
Number of queues	8
Jumbo frames support	Yes
Jumbo frames	9000
Packet buffer memory	1.5 MB

Security

Specification	Value
DHCP features	DHCP client
Access Control List (ACL)	Yes
IGMP snooping	Yes
Authentication	MAC-based authentication
BPDU filtering/protection	Yes
MAC address filtering	Yes
SSH/SSL support	Yes
Security algorithms	802.1x RADIUS, SNMP, SSH, SSH-2

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Rack mounting	Yes
Stackable	Yes
Form factor	1U
Product colour	Black
Safety	LVD, BSMI
Electromagnetic compatibility	FCC 15 (A), CE (A), BSMI

Performance

Specification	Value
Noise level	44.15 dB
Plug and Play	Yes
Mean time between failures (MTBF)	970594 h

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	45 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	No

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	10 - 90%
Heat dissipation	153.3 BTU/h

Weight & dimensions

Specification	Value
Width	441 mm
Depth	270 mm
Height	45 mm
Weight	3.86 kg

Packaging content

Specification	Value
Cables included	AC
Rack mount kit	Yes

Packaging data

Specification	Value
Package width	622 mm
Package depth	358 mm
Package height	108 mm
Package weight	4.92 kg

Certificates

Specification	Value
Certification	RoHS

Logistics data

Specification	Value
Harmonized System (HS) code	85176990
