Zyxel NSW100-28P Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Zyxel NSW100-28P Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Model NSW100-28PPart no. NSW100-28P-EU0101FEAN 4718937592180

63 specifications
  • Noise59.6 dB
  • Weight4.79 kg
  • ColourBlack, Grey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity28
  • 10G supportNo
See all specifications

Overview

Noise
59.6 dB
Weight
4.79 kg
Colour
Black, Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
28
10G support
No
Brand
Zyxel
Model
NSW100-28P
Part numbers
NSW100-28P-EU0101F, NSW100-28P-GB0101F, NSW100-28P-EU010F
EAN / UPC
4718937592180, 4718937590421, 5057103235735
Also known as
Zyxel NSW100-28P Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Specifications

63 specifications in 16 groups

Management features

Switch typeManaged
Switch layerL2
Web-based managementYes
System event logYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity28
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Combo SFP ports quantity4
Fiber optic connectorSFP+
USB 2.0 ports quantity1
Power connectorAC-in jack

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroringYes
Flow control supportYes
Link aggregationYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresTagged VLAN, Port-based VLAN

Optical fiber

Fiber ethernet cabling technology1000BASE-X

Data transmission

MAC address table16000 entries
Switching capacity56 Gbit/s
Throughput41.67 Mpps
Number of trunks8
Number of queues8
Packet buffer memory1.5 MB

Security

DHCP featuresDHCP client
IGMP snoopingYes
AuthenticationGuest VLAN, Port-based authentication
SSH/SSL supportYes
Security algorithms802.1x RADIUS, SNMP

Multicast features

Multicast supportYes

Design

Rack mountingYes
Product colourBlack, Grey
SafetyLVD, BSMI
Electromagnetic compatibilityFCC 15 A, CE EMC, BSMI EMC

Performance

Noise level59.6 dB
Mean time between failures (MTBF)1155719 h

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)454 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet plus (PoE+) ports quantity24
Total Power over Ethernet (PoE) budget375 W

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 95%
Heat dissipation162555 BTU/h

Weight & dimensions

Width440 mm
Depth330 mm
Height44.5 mm
Weight4.79 kg

Packaging content

Cables includedAC
ManualYes
Rack mount kitYes

Packaging data

Package width583 mm
Package depth451 mm
Package height98 mm
Package weight5.75 kg

Certificates

CertificationRoHS
