NSG100-ZZ0102F network switch Managed Gigabit Ethernet (10/100/1000) White
Model NSG100-ZZ0102F
38 specifications
- Weight1.25 kg
- ColourWhite
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity4
- 10G supportNo
- Throughput650 Mpps
Overview
- Weight
- 1.25 kg
- Colour
- White
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 4
- 10G support
- No
- Throughput
- 650 Mpps
- Brand
- Zyxel
- Category
- Network Switch
- Model
- NSG100-ZZ0102F
- Part number
- NSG100-ZZ0102F
- Also known as
- Zyxel NSG100-ZZ0102F network switch Managed Gigabit Ethernet (10/100/1000) White
Specifications
38 specifications in 12 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| MIB support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Console port | DB9 |
| USB 2.0 ports quantity | 2 |
Network
| Specification | Value |
|---|---|
| 10G support | No |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| VLAN support | Yes |
Data transmission
| Specification | Value |
|---|---|
| Throughput | 650 Mpps |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP client |
| Security algorithms | 3DES, 256-bit AES, DES, IPSec, SHA-1, SHA-512 |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | White |
| LED indicators | Yes |
| Number of fans | 0 fan(s) |
| On/off switch | Yes |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 815463.9 h |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| DC input voltage | 12 V |
| Input current | 3 A |
| Power consumption (max) | 19 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 242 mm |
| Depth | 36 mm |
| Height | 175 mm |
| Weight | 1.25 kg |
Packaging data
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Package width | 394 mm |
| Package depth | 101 mm |
| Package height | 240 mm |
| Package weight | 2.25 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | EMC FCC Part 15 (Class B) CE EMC (Class B) C-Tick (Class B), BSMI Safety LVD (EN60950-1) BSMI |
