Zyxel GS1920-24HPv2 & NWA1123ACv2

Model GS1920-24HPv2 & NWA1123ACv2Part no. GS192024HPV2-GB0103FEAN 4718937610167

56 specifications

Overview

Brand: Zyxel
Category: Network Switch
Model: GS1920-24HPv2 & NWA1123ACv2
Part number: GS192024HPV2-GB0103F
EAN / UPC: 4718937610167
Also known as: Zyxel GS1920-24HPv2 & NWA1123ACv2 Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

56 specifications in 14 groups

Specification	Value
Switch type	Managed
Quality of Service (QoS) support	Yes
ARP inspection	Yes
System event log	Yes
MIB support	RFC 1066, RFC 1213, RFC 1157, RFC 1493, RFC 1643, RFC 1757, RFC 2011.2012,2013, RFC 2233, RFC 2358, RFC 2674, RFC 2819,2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292, RFC 4293

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity	4
Fiber optic connector	SFP

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Copper ethernet cabling technology	100BASE-TX, 1000BASE-T
Flow control support	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	IP subnet–based VLAN, MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN

Specification	Value
DHCP features	DHCP client, DHCP relay, DHCP snooping, DHCPv6 relay
Access Control List (ACL)	Yes
IGMP snooping	Yes
Authentication	Guest VLAN, Port-based authentication
Authentication type	IEEE 802.1x, RADIUS
IP-MAC-Port binding	Yes
Password protection	Yes
Queue scheduling algorithms	SPQ, WFQ, Weighted Round Robin (WRR)
Security algorithms	802.1x RADIUS, SNMP, SNMPv3

Specification	Value
Multicast support	Yes

Specification	Value
Rack mounting	Yes
Product colour	Black
LED indicators	Yes
Electromagnetic compatibility	FCC 15 A, CE A, BSMI EMC

Specification	Value
Internal memory	256 MB
Flash memory	32 MB
Noise level	27.2 dB
Mean time between failures (MTBF)	638691 h

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	24
Total Power over Ethernet (PoE) budget	375 W

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	10 - 95%
Heat dissipation	1580.54 BTU/h

Specification	Value
Cables included	AC

Specification	Value
Certification	RoHS
