GS1900-10HP Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Model GS1900-10HPPart no. GS1900-10HP-GB0102FEAN 4718937621217
48 specifications
- Type1U
- Weight720 g
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity8
- 10G supportNo
Overview
- Type
- 1U
- Weight
- 720 g
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 8
- 10G support
- No
- Brand
- Zyxel
- Category
- Network Switch
- Model
- GS1900-10HP
- Part numbers
- GS1900-10HP-GB0102F, GS1900-10HP-EU0101F, 3179, GS1900-10HP, GS1900-10HP-GB0101F, GS1900-10HP-EU0102F
- EAN / UPC
- 4718937621217, 4718937587810, 4718937588176, 760559123451 +2 more
- Also known as
- Zyxel GS1900-10HP Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Specifications
48 specifications in 15 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| MIB support | RFC 1213, RFC 2819, RFC 1215, RFC 1493 |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Console port | RJ-45 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 20 Gbit/s |
| Throughput | 14.88 Mpps |
| Jumbo frames | 9000 |
Security
| Specification | Value |
|---|---|
| IGMP snooping | Yes |
| Security algorithms | 802.1x RADIUS, SSL/TLS |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMP, RMON, ICMP, Syslog |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Wall mountable | Yes |
| Safety | LVD EN60950-1, BSMI CNS14336-1, CB IEC60950-1 |
Performance
| Specification | Value |
|---|---|
| Buffer size | 525 KB |
| Mean time between failures (MTBF) | 801.113 h |
Power
| Specification | Value |
|---|---|
| Input current | 1.7 A |
| Input voltage | 54 V |
| Power consumption (typical) | 96.2 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 77 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Heat dissipation | 65.472 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 250 mm |
| Depth | 104 mm |
| Height | 27 mm |
| Weight | 720 g |
Packaging data
| Specification | Value |
|---|---|
| Package width | 302 mm |
| Package depth | 227 mm |
| Package height | 64 mm |
| Package weight | 1.53 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, C-Tick, BSMI CNS13438 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
