GS1005HP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Silver
Model GS1005HPPart no. GS1005HP-EU0101FEAN 4718937603923
38 specifications
- Weight235 g
- ColourSilver
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity5
- 10G supportNo
- MAC address table2048 entries
Overview
- Weight
- 235 g
- Colour
- Silver
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 5
- 10G support
- No
- MAC address table
- 2048 entries
- Brand
- Zyxel
- Category
- Network Switch
- Model
- GS1005HP
- Part numbers
- GS1005HP-EU0101F, GS1005HP-GB0101F
- EAN / UPC
- 4718937603923, 4718937603930
- Also known as
- Zyxel GS1005HP Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Silver
Specifications
38 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 2048 entries |
| Switching capacity | 10 Gbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 9126 |
Design
| Specification | Value |
|---|---|
| Product colour | Silver |
Performance
| Specification | Value |
|---|---|
| Buffer size | 128 KB |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| Output voltage | 55 V |
| Output current | 1.3 A |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 60 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 121 mm |
| Depth | 75 mm |
| Height | 26 mm |
| Weight | 235 g |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| AC adapter included | Yes |
| Package width | 210 mm |
| Package depth | 132 mm |
| Package height | 78 mm |
| Package weight | 834 g |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, BSMI, EAC |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
