Zyxel GS-220048 Managed L2
Model GS-220048Part no. ZY-GS220048
34 specifications
- Speed1 Gbit/s
- ConnectivityWired
- Weight4 kg
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity44
- Copper ethernet cabling technology100Base-Tx, 10Base-T
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Weight
- 4 kg
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 44
- Copper ethernet cabling technology
- 100Base-Tx, 10Base-T
- Brand
- Zyxel
- Category
- Network Switch
- Model
- GS-220048
- Part number
- ZY-GS220048
- Also known as
- Zyxel GS-220048 Managed L2
Specifications
34 specifications in 12 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 44 |
| Gigabit Ethernet (copper) ports quantity | 4 |
| Combo SFP ports quantity | 2 |
| SFP/SFP+ slots quantity | 2 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | 100Base-Tx, 10Base-T |
| Broadcast storm control | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Rate limiting | Yes |
| Spanning tree protocol | Yes |
| Number of VLANs | 256 |
Data transmission
| Specification | Value |
|---|---|
| Maximum data transfer rate | 1 Gbit/s |
| Packet buffer memory | 0.5 MB |
Security
| Specification | Value |
|---|---|
| IGMP snooping | Yes |
| MAC address filtering | Yes |
| SSH/SSL support | Yes |
Design
| Specification | Value |
|---|---|
| Stackable | Yes |
Power
| Specification | Value |
|---|---|
| Input voltage | 100 - 240 V |
| Power consumption (typical) | 92.8 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 438 x 310 x 44.45 mm |
| Connectivity technology | Wired |
| Authentication method | RADIUS, TACACS+ |
| Input frequency | 50/60 Hz |
| Performance management | SNMP 1, 2, 3, Telnet CLI, RMON |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 4 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | - UL 60950-1 - CSA 60950-1 - EN 60950-1 - IEC 60950-1 - EU RoHS |
