Zyxel GS-1524 Managed
Model GS-1524Part no. ZY-GS1524
30 specifications
- Speed1 Gbit/s
- ConnectivityWired
- Weight3 kg
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity28
- Copper ethernet cabling technology10Base-T
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Weight
- 3 kg
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 28
- Copper ethernet cabling technology
- 10Base-T
- Brand
- Zyxel
- Category
- Network Switch
- Model
- GS-1524
- Part numbers
- ZY-GS1524, 3073, 91-010-159001B, ZYXGS-1524
- Also known as
- Zyxel GS-1524 Managed
Specifications
30 specifications in 12 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 28 |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Combo SFP ports quantity | 4 |
| SFP/SFP+ slots quantity | 4 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | 10Base-T |
| Port mirroring | Yes |
| Broadcast storm control | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 48 Gbit/s |
| Maximum data transfer rate | 1 Gbit/s |
| Jumbo frames support | Yes |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP client |
| Static port security | Yes |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMP v1, v2, v3, RMON |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 43 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 438 x 215 x 44.45 mm |
| Connectivity technology | Wired |
| Power requirements | 100 - 240 V AC, 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 3 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | UL 60950-1 CSA 60950-1 EN 60950-1 IEC 60950-1 |
