Zyxel ES-1100-8P network switch Unmanaged Power over Ethernet (PoE) Black
Model ES-1100-8P
43 specifications
- Speed0.1 Gbit/s
- ConnectivityWired
- Weight1.4 kg
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity8
Overview
- Speed
- 0.1 Gbit/s
- Connectivity
- Wired
- Weight
- 1.4 kg
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Brand
- Zyxel
- Category
- Network Switch
- Model
- ES-1100-8P
- Part number
- ES-1100-8P
- Also known as
- Zyxel ES-1100-8P network switch Unmanaged Power over Ethernet (PoE) Black
Specifications
43 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 100BASE-T, 10BASE-T |
| Auto MDI/MDI-X | Yes |
| Broadcast storm control | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 1000 entries |
| Supported data transfer rates | 10/100 Mb/s |
| Switching capacity | 1.6 Gbit/s |
| Maximum data transfer rate | 0.1 Gbit/s |
| Packet buffer memory | 0.09375 MB |
Design
| Specification | Value |
|---|---|
| Stackable | Yes |
| Product colour | Black |
| LED indicators | LAN, Power |
| Safety | EN 60950-1, EC 60950-1 |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 64 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Other features
| Specification | Value |
|---|---|
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Networking features | Fast Ethernet |
| Power LED | Yes |
| Connectivity LEDs | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 50 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 32 - 122 °F |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 262 mm |
| Depth | 184 mm |
| Height | 41 mm |
| Weight | 1.4 kg |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
Packaging data
| Specification | Value |
|---|---|
| Package width | 318 mm |
| Package depth | 275 mm |
| Package height | 73 mm |
| Package weight | 2.2 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | RoHS, FCC, CE |
