Zyxel ES-108A Unmanaged
Model ES-108APart no. ZYXES-108AEAN 4718937000289
21 specifications
- Speed0.1 Gbit/s
- ConnectivityWired
- Weight340 g
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity8
- Copper ethernet cabling technology100BASE-TX, 10BASE-T
Overview
- Speed
- 0.1 Gbit/s
- Connectivity
- Wired
- Weight
- 340 g
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Copper ethernet cabling technology
- 100BASE-TX, 10BASE-T
- Brand
- Zyxel
- Category
- Network Switch
- Model
- ES-108A
- Part numbers
- ZYXES-108A, ES108A, ZY-ES108A, ES-108A
- EAN / UPC
- 4718937000289, 760559113544, 3609740145834, 3609740154003
- Also known as
- Zyxel ES-108A Unmanaged
Specifications
21 specifications in 11 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
Network
| Specification | Value |
|---|---|
| Copper ethernet cabling technology | 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 1000 entries |
| Store-and-forward | Yes |
| Maximum data transfer rate | 0.1 Gbit/s |
| Packet buffer memory | 0.768 MB |
Design
| Specification | Value |
|---|---|
| Stackable | No |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 2.75 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 154.5 x 85 x 26 mm |
| Connectivity technology | Wired |
| Networking features | Fast Ethernet |
| Packet transfer speed | 14880PPS - 10BASE-T, 148800PPS - 100BASE-TX |
| Power requirements | 5VDC 0.6A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 340 g |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC Class B CE C-Tick |
