Zyxel ES-105E network switch Black
Model ES-105EEAN 4718937565580
37 specifications
- ConnectivityWired
- Weight125 g
- ColourBlack
- Basic switching RJ-45 Ethernet ports quantity5
- 10G supportNo
- MAC address table1 entries
Overview
- Connectivity
- Wired
- Weight
- 125 g
- Colour
- Black
- Basic switching RJ-45 Ethernet ports quantity
- 5
- 10G support
- No
- MAC address table
- 1 entries
- Brand
- Zyxel
- Category
- Network Switch
- Model
- ES-105E
- Part number
- ES-105E
- EAN / UPC
- 4718937565580, 4718937573981
- Also known as
- Zyxel ES-105E network switch Black
Specifications
37 specifications in 13 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 100BASE-T, 10BASE-T |
| Ethernet LAN data rates | 10,100 Mbit/s |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 1 entries |
Security
| Specification | Value |
|---|---|
| MAC address filtering | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
Power
| Specification | Value |
|---|---|
| Power source | AC/DC |
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| Input current | 0.6 A |
| Power consumption (typical) | 2.4 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 142 x 87 x 28 mm |
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Power LED | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 32 - 104 °F |
| Relative humidity | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 142 mm |
| Depth | 87 mm |
| Height | 28 mm |
| Weight | 125 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Manual | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 146 x 92 x 86 mm |
| Package width | 146 mm |
| Package depth | 92 mm |
| Package height | 86 mm |
| Package weight | 267 g |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC class B, C-Tick |
