TP-Link JetStream 8-Port Gigabit Smart PoE+ Switch with 2 SFP Slots

TP-Link JetStream 8-Port Gigabit Smart PoE+ Switch with 2 SFP Slots

Model TL-SG2210PPart no. TL-SG2210P V5EAN 8459730220134

70 specifications
  • ColourBlack
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity8
  • 10G supportNo
  • Fiber ethernet cabling technology1000BASE-X, 100BASE-FX
  • MAC address table8000 entries
See all specifications

Overview

Colour
Black
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
8
10G support
No
Fiber ethernet cabling technology
1000BASE-X, 100BASE-FX
MAC address table
8000 entries
Brand
TP-Link
Model
TL-SG2210P
Part numbers
TL-SG2210P V5, TL-SG2210P V3, TL-SG2210P
EAN / UPC
8459730220134, 690338941702, 5054484704478, 5715328298194 +9 more
Also known as
TP-Link JetStream 8-Port Gigabit Smart PoE+ Switch with 2 SFP Slots

Specifications

70 specifications in 17 groups

Management features

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportYes
Web-based managementYes
MIB supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP modules quantity0
Installed SFP+ modules quantity0
SFP module slots quantity2
Fiber ports quantity2
Fiber optic connectorSFP
Console portRJ-45

Network

Networking standardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology1000BASE-T, 1000BASE-TX, 10BASE-T
Port mirroringYes
Broadcast storm controlYes
Flow control supportYes
Link aggregationYes
Rate limitingYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresMAC address-based VLAN, Multicast VLAN, Protocol-based VLAN, Voice VLAN
Number of VLANs4000

Optical fiber

Fiber ethernet cabling technology1000BASE-X, 100BASE-FX
Fiber typeMulti-mode

Data transmission

MAC address table8000 entries
Switching capacity20 Gbit/s
Forwarding rate14.88 Mpps
Number of queues4
Jumbo frames supportYes
Jumbo frames9000
Packet buffer memory4.1 MB

Security

DHCP featuresDHCP client, DHCP snooping, DHCPv6 client, DHCPv6 snooping
Access Control List (ACL)Yes
IGMP snoopingYes
BPDU filtering/protectionYes
MAC address filteringYes
SSH/SSL supportYes
Security algorithmsSNMP, SSH, SSH-2

Multicast features

Multicast supportYes

Design

Product colourBlack
LED indicatorsLink, PoE, Power

Performance

Compatible operating systemsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.
FanlessYes
Minimum system requirementsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux.

Power

Power sourceAC
Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)75.3 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet plus (PoE+) ports quantity8
Total Power over Ethernet (PoE) budget58 W

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%

Weight & dimensions

Width209 mm
Depth126 mm
Height26 mm

Packaging content

Cables includedAC
Quick start guideYes

Packaging data

Package width240 mm
Package depth315 mm
Package height70 mm
Package weight1.25 kg

Certificates

CertificationCE, FCC, RoHS

Logistics data

Harmonized System (HS) code85176990
