TP-Link 48-Port Gigabit Rackmount Network Switch

TP-Link 48-Port Gigabit Rackmount Network Switch

Model TL-SG1048EAN 3548383171421

53 specifications
  • Speed1 Gbit/s
  • ConnectivityWired
  • Type1U
  • ColourBlack
  • Switch typeUnmanaged
  • Basic switching RJ-45 Ethernet ports quantity48
See all specifications

Overview

Speed
1 Gbit/s
Connectivity
Wired
Type
1U
Colour
Black
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
48
Brand
TP-Link
Model
TL-SG1048
Part numbers
TL-SG1048, TL-SG1048 V6, TL-SG1048 V4, TL-SG1048 V5
EAN / UPC
3548383171421, 168141533334, 845973020637, 6935364020637 +19 more
Also known as
TP-Link 48-Port Gigabit Rackmount Network Switch

Specifications

53 specifications in 13 groups

Management features

Switch typeUnmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity48
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Full duplexYes
Half duplexYes
Auto MDI/MDI-XYes
Auto-negotiationYes

Data transmission

MAC address table16000 entries
Supported data transfer rates10/100/1000 Mbps
Switching capacity96 Gbit/s
Forwarding rate71.4 Mpps
Store-and-forwardYes
Maximum data transfer rate1 Gbit/s
Jumbo frames supportYes
Jumbo frames12000

Protocols

Supported network protocolsCSMA/CD, TCP/IP

Design

Rack mountingYes
Form factor1U
Product colourBlack
LED indicatorsYes
Compatible productsFCC, CE

Power

Power sourceAC
Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)32.29 W

Other features

Dimensions (WxDxH)440 x 360 x 44 mm
Connectivity technologyWired
Bandwidth96 Gbit/s
Connectivity LEDsYes
Dimensions (W x D x H) (imperial)439.4 x 360.7 x 43.2 mm (17.3 x 14.2 x 1.7")

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Operating temperature (T-T)32 - 104 °F
Heat dissipation110.17 BTU/h

Weight & dimensions

Width440 mm
Depth220 mm
Height44 mm

Packaging content

Cables includedAC
Rack mount kitYes
User guideYes

Packaging data

Package typeBox
Package width528 mm
Package depth336 mm
Package height100 mm

Logistics data

Harmonized System (HS) code85176990
