TP-Link 5-Port Gigabit Desktop Network Switch

TP-Link 5-Port Gigabit Desktop Network Switch

Model TL-SG1005DEAN 6935364020255

51 specifications
  • ColourBlack
  • Switch typeUnmanaged
  • Basic switching RJ-45 Ethernet ports quantity5
  • 10G supportNo
  • MAC address table8000 entries
  • Maximum cable length100 m
See all specifications

Overview

Colour
Black
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
5
10G support
No
MAC address table
8000 entries
Maximum cable length
100 m
Brand
TP-Link
Model
TL-SG1005D
Part numbers
TL-SG1005D, TL-SG1005D V4, TL-SG1005D V6
EAN / UPC
6935364020255, 021111744706, 071040164113, 132309812111 +16 more
Also known as
TP-Link 5-Port Gigabit Desktop Network Switch

Specifications

51 specifications in 13 groups

Management features

Switch typeUnmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity5
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity5
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Power connectorDC-in jack

Network

Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G supportNo
Full duplexYes
Half duplexYes
Auto MDI/MDI-XYes
Auto-negotiationYes
Flow control supportYes
MAC address auto-aging supportedYes
MAC address auto-learning supportedYes

Data transmission

MAC address table8000 entries
Switching capacity10 Gbit/s
Store-and-forwardYes
Jumbo frames supportYes
Jumbo frames15000

Design

Rack mountingNo
StackableNo
Product colourBlack
LED indicatorsYes
Number of fans0 fan(s)

Performance

Compatible operating systemsMicrosoft Windows 2000/XP/2003/Vista/2008/7/2012/8/10, MacOS, NetWare, UNIX, Linux
Maximum cable length100 m
FanlessYes

Power

Power sourceDC
Power supply includedNo
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current0.6 A
Input voltage9 V
Power consumption (max)2.47 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Heat dissipation8.22 BTU/h

Weight & dimensions

Width165 mm
Depth108 mm
Height28 mm

Packaging content

Quick start guideYes

Packaging data

Package width108 mm
Package depth145 mm
Package height85 mm
Package weight180 g

Logistics data

Harmonized System (HS) code85176990
