5 Port Unmanaged Industrial Gigabit PoE Switch with 4 Power over Ethernet ports
Model IES51000POEEAN 012302532271
37 specifications
- Weight366 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity4
- 10G supportNo
- Fiber ethernet cabling technology100BASE-FX
Overview
- Weight
- 366 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 4
- 10G support
- No
- Fiber ethernet cabling technology
- 100BASE-FX
- Brand
- StarTech.com
- Category
- Network Switch
- Model
- IES51000POE
- Part number
- IES51000POE
- EAN / UPC
- 012302532271, 065030851916, 650308519164, 4058829198183
- Also known as
- StarTech.com 5 Port Unmanaged Industrial Gigabit PoE Switch with 4 Power over Ethernet ports
Specifications
37 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 5 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Copper ethernet cabling technology | 1000BASE-TX, 100BASE-TX, 10BASE-T |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
Optical fiber
| Specification | Value |
|---|---|
| Fiber ethernet cabling technology | 100BASE-FX |
Data transmission
| Specification | Value |
|---|---|
| Switching capacity | 2 Gbit/s |
| Store-and-forward | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Housing material | Steel |
| LED indicators | Yes |
Power
| Specification | Value |
|---|---|
| Number of power supply units | 1 |
| AC input voltage | 100 - 240 V |
| Input current | 2 A |
| Output power | 64.8 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 4 |
Other features
| Specification | Value |
|---|---|
| Power LED | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 90 mm |
| Depth | 130 mm |
| Height | 28 mm |
| Weight | 366 g |
Packaging content
| Specification | Value |
|---|---|
| Cables included | AC |
| Manual | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 201 mm |
| Package depth | 370 mm |
| Package height | 74 mm |
| Package weight | 1.41 kg |
