5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable - TAA
Model IES51000EAN 4058829198176
45 specifications
- Weight328 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity5
- 10G supportNo
- Switching capacity2 Gbit/s
Overview
- Weight
- 328 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 5
- 10G support
- No
- Switching capacity
- 2 Gbit/s
- Brand
- StarTech.com
- Category
- Network Switch
- Model
- IES51000
- Part number
- IES51000
- EAN / UPC
- 4058829198176, 065030859318, 650308593188, 5054629677650 +1 more
- Also known as
- StarTech.com 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable - TAA
Specifications
45 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u |
| 10G support | No |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Link aggregation | Yes |
Data transmission
| Specification | Value |
|---|---|
| Switching capacity | 2 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Steel |
| LED indicators | Activity, Link, Power |
| International Protection (IP) code | IP30 |
| Wall mountable | Yes |
Performance
| Specification | Value |
|---|---|
| Buffer size | 128 KB |
| Maximum cable length | 100 m |
Power
| Specification | Value |
|---|---|
| Input voltage | 12 - 58 V |
| Power consumption (typical) | 3.63 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 89 mm |
| Depth | 111 mm |
| Height | 28 mm |
| Weight | 328 g |
Packaging content
| Specification | Value |
|---|---|
| Manual | Yes |
Packaging data
| Specification | Value |
|---|---|
| DIN rail included | Yes |
| Mounting brackets included | Yes |
| Screws included | Yes |
| Terminal block included | Yes |
| Wall mounting kit | Yes |
| Package width | 139 mm |
| Package depth | 178 mm |
| Package height | 83 mm |
| Package weight | 523 g |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC, RoHS, REACH |
Logistics data
| Specification | Value |
|---|---|
| Master (outer) case width | 440 mm |
| Master (outer) case length | 550 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case height | 362 mm |
| Products per master (outer) case | 36 pc(s) |
