Product comparison · 2 network switches

SilverNet SIL 534C24MP vs SilverNet SIL 54224MP

Add a product
  • 56specifications compared
  • 12differ
  • 44identical
  • 53known for one product only

Key differences

  • Switch layer
    • L2+
    • L3
  • Fiber optic connector
    • LC, SFP
    • LC
  • 10G support
    • No
    • Yes
  • MAC address table
    • 8000 entries
    • 16000 entries
  • Switching capacity
    • 56 Gbit/s
    • 128 Gbit/s
  • Form factor
    • 19U
    • 1U
  • Housing material
    • Aluminium
    • Metal
  • Mean time between failures (MTBF)
    • 250000 h
    • 100819 h

Side by side

Differences highlightedShow differences only
109 specifications
A

SilverNet

SIL 534C24MPView product
B

SilverNet

SIL 54224MPView product
Management features1 differ
Switch typeManagedManaged
Switch layerDiffersL2+L3
Quality of Service (QoS) supportYesYes
Web-based managementYesYes
ARP inspectionKnown for oneYes
Traffic classificationKnown for oneYes
Traffic shapingKnown for oneYes
System event logKnown for oneYes
Configuring Location Settings (CLI)Known for oneYes
Ports & interfaces1 differ
Basic switching RJ-45 Ethernet ports quantity2424
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)Gigabit Ethernet (10/100/1000)
Fast Ethernet (copper) ports quantityKnown for one24
Gigabit Ethernet (copper) ports quantityKnown for one24
Combo SFP ports quantity44
SFP module slots quantityKnown for one4
Fiber optic connectorDiffersLC, SFPLC
Power connectorAC-in jackAC-in jack
Console portKnown for oneDB9
Network2 differ
Networking standardsDiffersIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3zIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportDiffersNoYes
Copper ethernet cabling technology10BASE-TX, 100BASE-TX, 1000BASE-TX10BASE-TX, 100BASE-TX, 1000BASE-TX
Port mirroringKnown for oneYes
Full duplexYesYes
Half duplexYesYes
IP routingKnown for oneYes
Auto MDI/MDI-XYesYes
Auto-negotiationYesYes
Broadcast storm controlKnown for oneYes
Flow control supportKnown for oneYes
Link aggregationKnown for oneYes
Rate limitingKnown for oneYes
Spanning tree protocolYesYes
VLAN supportYesYes
Virtual LAN featuresKnown for oneMultiple VXLAN (MUX VLAN), Port-based VLAN, Tagged VLAN
Number of VLANs256256
Auto-sensingKnown for oneYes
Ethernet LAN data ratesKnown for one1000 Mbit/s
Optical fiberidentical
Fiber ethernet cabling technologyKnown for one1000Base-X
Data transmission2 differ
MAC address tableDiffers8000 entries16000 entries
Switching capacityDiffers56 Gbit/s128 Gbit/s
Store-and-forwardYesYes
Latency (10-100 Mbps)7 µs7 µs
Latency (1 Gbps)Known for one7 µs
Static routeKnown for oneYes
Jumbo frames supportYesYes
Jumbo frames1000010000
Packet buffer memoryKnown for one4 MB
Securityidentical
DHCP featuresKnown for oneDHCP client, DHCP server, DHCPv6 client, DHCPv6 server
Access Control List (ACL)YesYes
IGMP snoopingYesYes
AuthenticationKnown for oneMAC-based authentication, Port-based authentication
Authentication typeKnown for oneIEEE 802.1x, RADIUS
IP-MAC-Port bindingKnown for oneYes
Loop protectionYesYes
MAC address entriesKnown for oneBlackhole MAC address entries, Static MAC address entries
MAC address filteringKnown for oneYes
Password protectionKnown for oneYes
Queue scheduling algorithmsKnown for oneSP, WRR+SP, Weighted Round Robin (WRR)
SSH/SSL supportKnown for oneYes
Security algorithmsKnown for one802.1x RADIUS, HTTPS, SNMPv3, SSH-2, SSL/TLS
Static port securityKnown for oneYes
Multicast featuresidentical
Multicast supportYesYes
Design2 differ
Rack mountingYesYes
StackableKnown for oneYes
Form factorDiffers19U1U
Product colourBlackBlack
Housing materialDiffersAluminiumMetal
LED indicatorsKnown for oneAlarm, LAN, Link, Power, Ring
International Protection (IP) codeKnown for oneIP30
Electromagnetic compatibilityKnown for oneEN55032 Class A, CISPR 32 FCC Part 15B Class A, EN61000 4 2 (ESD) EN61000 4 3 (RS) EN61000 4 4 (EFT) EN61000 4 5 (Surge) EN61000 4 6 (CS) EN61000 4 8 (PFMF)
Performance1 differ
Firmware upgradeableYesYes
Noise levelKnown for one0 dB
FanlessYesYes
Mean time between failures (MTBF)Differs250000 h100819 h
Poweridentical
Power sourceACAC
Redundant power supply (RPS) supportKnown for oneYes
Number of power supply unitsKnown for one2
AC input voltage100 - 240 V100 - 240 V
Power consumption (max)Known for one24 W
Power protection featuresKnown for oneOverload, Reverse polarity
Power supply includedKnown for oneYes
AC input frequencyKnown for one50/60 Hz
Power consumption (typical)Known for one24 W
Power over Ethernet (PoE)1 differ
Power over Ethernet (PoE)YesYes
Power over Ethernet (PoE) type supportedActive PoEActive PoE
Power over Ethernet (PoE) ports quantity2424
Power over Ethernet (PoE) voltageKnown for one48 V
Power over Ethernet (PoE) power per port30 W30 W
Total Power over Ethernet (PoE) budgetDiffers720 W480 W
Other featuresidentical
Warranty period3 year(s)3 year(s)
Operational conditionsidentical
Operating temperature (T-T)0 - 50 °C0 - 50 °C
Storage temperature (T-T)-20 - 70 °C-20 - 70 °C
Operating relative humidity (H-H)5 - 90%5 - 90%
Weight & dimensions1 differ
WidthDiffers440 mm400 mm
Depth300 mm300 mm
Height45 mm45 mm
Weight4 kg4 kg
Packaging contentidentical
Cables includedACAC
Quick start guideYesYes
Rack mount kitYesYes
Packaging dataidentical
Package typeBoxBox
Package widthKnown for one393 mm
Package depthKnown for one495 mm
Package heightKnown for one80 mm
Package weightKnown for one5.08 kg
Certificates1 differ
CertificationDiffersIEC/EN 62368-1 IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 RoHSFCC Part15 Class A CE-EMC/LVD RoHS EN61000-4-2 (ESD):LEVEL 4 IEC 6100-4-2 (EFT):LEVEL 4 IEC 6100-4-2 (Surge): LEVEL 4 IEC 6100-4-2 (CS)：LEVEL 3 IEC 61000-4-2(PFMP) : LEVEL 5 EN61000-4-3 (RS):LEVEL 4 IEC60068-2-27 IEC60068-2-6 IEC60068-2-31 EN 60950 1, UL 60950 1, CSA C22.2 No.60950 1, UL 508
Logistics dataidentical
UK Trade Tariff codeKnown for one85176200
Country of originKnown for oneUnited Kingdom
Protocolsidentical
GARP VLAN Registration Protocol (GVRP)Known for oneYes

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
