QSW-2104-2T network switch Unmanaged
2.5G Ethernet (100/1000/2500) Black
Model QSW-2104-2TEAN 4713213518809
38 specifications
- Weight722 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity6
- 10G supportYes
- MAC address table16000 entries
Overview
- Weight
- 722 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 6
- 10G support
- Yes
- MAC address table
- 16000 entries
- Brand
- QNAP
- Category
- Network Switch
- Model
- QSW-2104-2T
- Part number
- QSW-2104-2T
- EAN / UPC
- 4713213518809
- Also known as
- QNAP QSW-2104-2T network switch Unmanaged 2.5G Ethernet (100/1000/2500) Black
Specifications
38 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 6 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (copper) ports quantity | 4 |
| 10G Ethernet (copper) ports quantity | 2 |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u |
| 10G support | Yes |
| Copper ethernet cabling technology | 1000BASE-LX, 1000BASE-SX, 1000BASE-T |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 60 Gbit/s |
| Throughput | 30 Gbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Stackable | No |
| Product colour | Black |
| LED indicators | Activity, Link, Power, Speed, Status |
| Electromagnetic compatibility | Class B |
Performance
| Specification | Value |
|---|---|
| Fanless | Yes |
Power
| Specification | Value |
|---|---|
| Power source | DC |
| Power supply included | Yes |
| DC input voltage | 12 V |
| Input current | 1 A |
| Power consumption (max) | 12 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 180 mm |
| Depth | 145 mm |
| Height | 34 mm |
| Weight | 722 g |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
| User guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 1.02 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | FCC, CE, BSMI, VCCI, LVD,CCC,KCC |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
