QNAP QGD-1602-C3758-16G network switch Managed L2

QGD-1602-C3758-16G network switch Managed L2

2.5G Ethernet (100/1000/2500) Black, Grey

Model QGD-1602-C3758-16GEAN 885022026616

69 specifications

ProcessorAtom C3758
Memory16000 MB
Weight4.37 kg
ColourBlack, Grey
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity16

See all specifications

Overview

Processor: Atom C3758
Memory: 16000 MB
Weight: 4.37 kg
Colour: Black, Grey
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 16

Brand: QNAP
Category: Network Switch
Model: QGD-1602-C3758-16G
Part number: QGD-1602-C3758-16G
EAN / UPC: 885022026616, 4711103084267
Also known as: QNAP QGD-1602-C3758-16G network switch Managed L2 2.5G Ethernet (100/1000/2500) Black, Grey

Specifications

69 specifications in 18 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
Traffic classification	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Gigabit Ethernet (copper) ports quantity	8
2.5G Ethernet (copper) ports quantity	8
SFP+ module slots quantity	2

Network

Specification	Value
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Yes
Copper ethernet cabling technology	10BASE-TX, 1000BASE-T
Port mirroring	Yes
Full duplex	Yes
Auto-negotiation	Yes
Flow control support	Yes
Link aggregation	Yes
Rate limiting	Yes
VLAN support	Yes
Virtual LAN features	Port-based VLAN
Port trunking	Yes

Optical fiber

Specification	Value
Fiber ethernet cabling technology	10GBASE-LR, 10GBASE-SR, 1000Base-X

Data transmission

Specification	Value
MAC address table	32000 entries
Switching capacity	96 Gbit/s
Throughput	48 Gbit/s
Jumbo frames support	Yes
Jumbo frames	9000

Security

Specification	Value
DHCP features	DHCP client, DHCP server
Access Control List (ACL)	Yes
IGMP snooping	Yes
Loop protection	Yes
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH, SSL/TLS

Multicast features

Specification	Value
Multicast MAC address table	8000 entries

Design

Specification	Value
Rack mounting	Yes
Product colour	Black, Grey
Reset button	Yes
LED indicators	Activity, Alarm, Link, PoE, Speed

Performance

Specification	Value
Built-in processor	Yes
Processor manufacturer	Intel
Processor model	Atom C3758
Processor frequency	2200 MHz
Internal memory	16000 MB
Flash memory	4000 MB

Power

Specification	Value
Power source	AC
Power supply included	Yes
AC input voltage	100 - 240 V
Power consumption (max)	100 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	No

Other features

Specification	Value
Expansion slots	2x PCIe Gen3 (x4 slot, x2 speed)
I/O ports	2x USB 3.2 Gen 1, 2 x 5GbE, 2 x 1GbE
Warranty period	2 year(s)

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95%

Weight & dimensions

Specification	Value
Width	436.2 mm
Depth	326.2 mm
Height	47.2 mm
Weight	4.37 kg

Packaging content

Specification	Value
Cables included	AC, LAN (RJ-45)
Quick start guide	Yes
Rack mount kit	Yes

Packaging data

Specification	Value
Package type	Box
Package width	530 mm
Package depth	403 mm
Package height	160 mm
Package weight	5.56 kg

Certificates

Specification	Value
Certification	FCC, VCCI, BSMI RCM, CCC

Logistics data

Specification	Value
Country of origin	Taiwan
Products per master (outer) case	2 pc(s)
