NETGEAR XS512EM Managed L2

NETGEAR XS512EM Managed L2

10G Ethernet (100/1000/10000) 1U Blue, Grey

Model XS512EMPart no. XS512EM-100EUSEAN 606449129458

44 specifications
  • Type1U
  • Weight2.51 kg
  • ColourBlue, Grey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity12
  • 10G supportYes
See all specifications

Overview

Type
1U
Weight
2.51 kg
Colour
Blue, Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
12
10G support
Yes
Brand
NETGEAR
Model
XS512EM
Part numbers
XS512EM-100EUS, XS512EM-100AJS, XS512EM-100NAS
EAN / UPC
606449129458, 606449129441, 606449129434
Also known as
NETGEAR XS512EM Managed L2 10G Ethernet (100/1000/10000) 1U Blue, Grey

Specifications

44 specifications in 14 groups

Management features

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity12
Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
SFP+ module slots quantity2
Power connectorDC-in jack

Network

Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportYes
Broadcast storm controlYes
VLAN supportYes
Virtual LAN featuresPort-based VLAN
Number of VLANs64

Data transmission

MAC address table32000 entries
Switching capacity240 Gbit/s
Store-and-forwardYes
Jumbo frames supportYes
Jumbo frames9000
Packet buffer memory3 MB

Security

DHCP featuresDHCP client
IGMP snoopingYes
MAC address filteringYes

Design

Rack mountingYes
Form factor1U
Product colourBlue, Grey
LED indicatorsYes
Number of fans2 fan(s)

Performance

Mean time between failures (MTBF)1113477 h

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current2 A

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 95%
Heat dissipation261.38 BTU/h

Weight & dimensions

Width328 mm
Depth204 mm
Height43 mm
Weight2.51 kg

Sustainability

Sustainability certificatesENERGY STAR

Certificates

Certification47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN55032:2012+AC:2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2013, VCCI-CISPR32:2016, CNS 13438, IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:20

Logistics data

Harmonized System (HS) code85176990
