NETGEAR XS508M Unmanaged

NETGEAR XS508M Unmanaged

10G Ethernet (100/1000/10000) Grey, Silver

Model XS508MPart no. XS508M-100EUSEAN 606449131116

35 specifications
  • Weight1.49 kg
  • ColourGrey, Silver
  • Switch typeUnmanaged
  • Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
  • 10G supportYes
  • MAC address table2000 entries
See all specifications

Overview

Weight
1.49 kg
Colour
Grey, Silver
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
10G support
Yes
MAC address table
2000 entries
Brand
NETGEAR
Model
XS508M
Part numbers
XS508M-100EUS, XS508M-100NAS
EAN / UPC
606449131116, 606449131123
Also known as
NETGEAR XS508M Unmanaged 10G Ethernet (100/1000/10000) Grey, Silver

Specifications

35 specifications in 11 groups

Management features

Switch typeUnmanaged
Quality of Service (QoS) supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
Gigabit Ethernet (copper) ports quantity7
SFP+ module slots quantity1
Power connectorDC-in jack

Network

Networking standardsIEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportYes

Data transmission

MAC address table2000 entries
Switching capacity160 Gbit/s
Jumbo frames supportYes
Jumbo frames9000

Design

Rack mountingYes
Product colourGrey, Silver
LED indicatorsYes
SafetyCE: CB 60950-1, LVD 60950-1, AUS/NZ: AS/NZS 60950-1, USA: UL 60950-1, SNE VA, BSMI

Performance

Mean time between failures (MTBF)1145157 h

Power

Power sourceAC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1.5 A
Power consumption (typical)21.31 W
Power consumption (max)39 W

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Heat dissipation147.86 BTU/h

Weight & dimensions

Width328 mm
Depth169 mm
Height43.2 mm
Weight1.49 kg

Certificates

Certification47 CFR FCC, ICES-003:2016 Issue 6, ANSI C63.4:2014, EN 55032:2012+AC2013, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 32:2015, VCCI V-3/2015.04, V-4/2012.4, CNS 13438

Logistics data

Harmonized System (HS) code85176990
