NETGEAR WFS709TP Managed L3 Power over Ethernet (PoE) Blue
Model WFS709TPPart no. WFS709TP-100EUSEAN 606449052190
31 specifications
- Memory256 MB
- Speed1 Gbit/s
- ConnectivityWireless
- Weight4.5 kg
- ColourBlue
- Switch typeManaged
Overview
- Memory
- 256 MB
- Speed
- 1 Gbit/s
- Connectivity
- Wireless
- Weight
- 4.5 kg
- Colour
- Blue
- Switch type
- Managed
- Brand
- NETGEAR
- Category
- Network Switch
- Model
- WFS709TP
- Part number
- WFS709TP-100EUS
- EAN / UPC
- 606449052190, 5051749448641
- Also known as
- NETGEAR WFS709TP Managed L3 Power over Ethernet (PoE) Blue
Specifications
31 specifications in 12 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Gigabit Ethernet (copper) ports quantity | 1 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 4096 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Throughput | 1 Gbps |
| Maximum data transfer rate | 1 Gbit/s |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server |
| MAC address filtering | Yes |
| Security algorithms | WPA, WPA2 |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Product colour | Blue |
Performance
| Specification | Value |
|---|---|
| Internal memory | 256 MB |
| Flash memory | 256 MB |
| Mean time between failures (MTBF) | 43800 h |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 200 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 442 x 330 x 44.5 mm |
| Connectivity technology | Wireless |
| Power requirements | 90-132V AC, 180-246V AC |
| Wi-Fi | Yes |
| Connectivity LEDs | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 70% |
| Storage relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 4.5 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, PSE Mark, (CAN/CSA) C22.2 No. 60950, EN 60950 / IEC 60950 CB, FCC 15 A, VCCI A, AS/NZS CISPR 22 A, AS/NZS4771 |
