NETGEAR ProSafe Plus JGS524PE

Model ProSafe Plus JGS524PEPart no. JGS524PE-100EUSEAN 606449098983

64 specifications

Overview

Brand: NETGEAR
Category: Network Switch
Model: ProSafe Plus JGS524PE
Part number: JGS524PE-100EUS
EAN / UPC: 606449098983, 5052916774549, 6064490989836
Also known as: NETGEAR ProSafe Plus JGS524PE Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

64 specifications in 15 groups

Specification	Value
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Web-based management	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Compatible memory cards	Not supported
Power connector	DC-in jack

Specification	Value
Networking standards	IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
10G support	No
Copper ethernet cabling technology	1000BASE-T, 100BASE-T, 10BASE-T
Port mirroring	Yes
Full duplex	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Rate limiting	Yes
VLAN support	Yes
Virtual LAN features	Tagged VLAN, Port-based VLAN
Number of VLANs	100

Specification	Value
DHCP features	DHCP client
IGMP snooping	Yes
DoS attack prevention	Yes
Loop protection	Yes
MAC address filtering	Yes
Queue scheduling algorithms	SP, Weighted Round Robin (WRR)

Specification	Value
Multicast support	Yes
Number of multicast groups filtered	64

Specification	Value
Supported network protocols	IEEE 802.3, IEEE 802.3i,IEEE 802.3u, IEEE802.3ab, IEEE 802.1p,IEEE 802.3 af, IEEE 802.1Q, IEEE 802.3x

Specification	Value
Rack mounting	Yes
Product colour	Black
LED indicators	Activity, Link, PoE, Power, Speed, Status
Number of fans	1 fan(s)

Specification	Value
Buffer size	768 KB
Noise level	24.4 dB
Mean time between failures (MTBF)	643506 h

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	12
Total Power over Ethernet (PoE) budget	100 W

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 3000 m
Heat dissipation	78.7 BTU/h

Specification	Value
Cables included	AC
Quick start guide	Yes

Specification	Value
Certification	CE, CSA, UL 1950/cUL IEC 950/EN 60950
