NETGEAR ProSafe Managed Switch
Model ProSafe Managed SwitchPart no. GSM7224AU
39 specifications
- Speed100 Gbit/s
- ConnectivityWired
- Noise60 dB
- Weight4.2 kg
- ColourBlue
- Switch typeManaged
Overview
- Speed
- 100 Gbit/s
- Connectivity
- Wired
- Noise
- 60 dB
- Weight
- 4.2 kg
- Colour
- Blue
- Switch type
- Managed
- Brand
- NETGEAR
- Category
- Network Switch
- Model
- ProSafe Managed Switch
- Part numbers
- GSM7224AU, GSM7248AU, GSM7248R-100AUS, GSM7224R-100AUS
- Also known as
- NETGEAR ProSafe Managed Switch L2 Blue
Specifications
39 specifications in 14 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| System event log | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Port mirroring | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
Data transmission
| Specification | Value |
|---|---|
| Number of trunks | 6 |
| Number of queues | 8 |
| Maximum data transfer rate | 100 Gbit/s |
Security
| Specification | Value |
|---|---|
| IGMP snooping | Yes |
| MAC address filtering | Yes |
| Static port security | Yes |
Protocols
| Specification | Value |
|---|---|
| Supported network protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x |
Design
| Specification | Value |
|---|---|
| Stackable | No |
| Product colour | Blue |
Performance
| Specification | Value |
|---|---|
| Firmware upgradeable | Yes |
| Noise level | 60 dB |
| Mean time between failures (MTBF) | 58300 h |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 42.9 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Latency | <20µs |
| Dimensions (WxDxH) | 440 x 257 x 43 mm |
| Connectivity technology | Wired |
| Bandwidth | 35.7 Gbit/s |
| Power requirements | 100-240VAC/50-60 Hz |
| Connectivity LEDs | Yes |
| Non-operating relative humidity (non-condensing) | 0 - 95% |
| Weight (imperial) | 4.17 kg (9.2 lbs) |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating altitude | 0 - 3000 m |
| Operating temperature (T-T) | 32 - 122 °F |
| Heat dissipation | 28.4 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 4.2 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE mark EN 55022 Class A - Emissions EN 55024 - Immunity FCC Part 15 Class A VCCI Class A C-Tick |
