Netzwerkgeräte Managed L2/L3/L4 1U Black
Model NetzwerkgerätePart no. M4500-48XF8C
87 specifications
- ProcessorAtom C3558
- Memory8000 MB
- Noise68 dB
- Type1U
- Weight9.78 kg
- ColourBlack
Overview
- Processor
- Atom C3558
- Memory
- 8000 MB
- Noise
- 68 dB
- Type
- 1U
- Weight
- 9.78 kg
- Colour
- Black
- Brand
- NETGEAR
- Category
- Network Switch
- Model
- Netzwerkgeräte
- Part number
- M4500-48XF8C
- Also known as
- NETGEAR Netzwerkgeräte Managed L2/L3/L4 1U Black
Specifications
87 specifications in 15 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2/L3/L4 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| ARP inspection | Yes |
| Configuring Location Settings (CLI) | Yes |
| System event log | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports type | No |
| Console port | RS-232/RJ-45 |
| QSFP28 ports quantity | 8 |
| SFP28 ports quantity | 48 |
| USB 2.0 ports quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3ad, IEEE 802.1AX, IEEE 802.1w, IEEE 802.1s, IEEE 802.1x, IEEE 802.1p, IEEE 1588v2, IEEE 802.1ab |
| 10G support | Yes |
| Port mirroring | Yes |
| Policy-based routing | Yes |
| Broadcast storm control | Yes |
| IPv4 routes | 32000 |
| IPv6 routes | 24000 |
| Link aggregation | Yes |
| QinQ implementation | QinQ |
| Spanning tree protocol | Yes |
| Number of VLANs | 4093 |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 32000 entries |
| Switching capacity | 4000 Gbit/s |
| Number of queues | 8 |
| Static route | Yes |
| Number of static routes | 128 |
| Number of IP interfaces | 128 |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 256 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP Option 82, DHCP relay, DHCP client, DHCPv6 client, DHCPv6 relay |
| Access Control List (ACL) | Yes |
| Access Control List (ACL) rules | 16384 |
| IGMP snooping | Yes |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication |
| Authentication type | TACACS+, RADIUS |
| Auto-edge port | Yes |
| BPDU filtering/protection | Yes |
| Loop protection | Yes |
| Password protection | Yes |
| Root protection | Yes |
| SSH/SSL support | Yes |
| Security algorithms | SNMP, SSH, SSH-2, SNMPv2c, SNMPv3 |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
| IPv6 multicast entries | 512 |
| MLD entries | 64 |
| Multicast Listener Discovery (MLD) snooping | Snooping v1/v2 |
Protocols
| Specification | Value |
|---|---|
| Virtual Router Redundancy Protocol (VRRP) | Yes |
| IP Source Guard (IPSG) | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Reset button | Yes |
| LED indicators | Yes |
| Redundant fans support | Yes |
| Number of fans | 6 fan(s) |
Performance
| Specification | Value |
|---|---|
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor model | Atom C3558 |
| Memory type | DDR3L-SDRAM |
| Internal memory | 8000 MB |
| Flash memory | 128000 MB |
| Noise level | 68 dB |
| Telnet | Yes |
| sFlow | Yes |
| Mean time between failures (MTBF) | 289052 h |
Power
| Specification | Value |
|---|---|
| Power source | AC |
| Power supply included | Yes |
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| Power consumption (max) | 394 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Switch fabric speed | 4 Tbps |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 3000 m |
| Heat dissipation | 1344.4 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 440 mm |
| Depth | 508 mm |
| Height | 43.2 mm |
| Weight | 9.78 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE: EN 55032:2012+AC:2013/CISPR 32:2012, EN 61000-3-2:2014, Class A, EN 61000-3-3:2013, EN 55024:2010 VCCI : VCCI-CISPR 32:2016, Class A RCM: AS/NZS CISPR 32:2013 Class A CCC: GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A) FCC: 47 CFR FCC Part 15, Class A, ANSI C63.4:2014 ISED: ICES-003:2016 I |
