NETGEAR MS510TXPP Managed L2/L3/L4

10G Ethernet (100/1000/10000) Power over Ethernet (PoE) Grey

Model MS510TXPPPart no. MS510TXPP-100EUSEAN 10606449120957

71 specifications

Overview

Brand: NETGEAR
Category: Network Switch
Model: MS510TXPP
Part numbers: MS510TXPP-100EUS, MS510TXPP-100NAS, MS510TXPP-100AJS
EAN / UPC: 10606449120957, 606449120967, 606449120974
Also known as: NETGEAR MS510TXPP Managed L2/L3/L4 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) Grey

71 specifications in 14 groups

Specification	Value
Switch type	Managed
Switch layer	L2/L3/L4
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Gigabit Ethernet (copper) ports quantity	4
2.5G Ethernet (copper) ports quantity	2
10G Ethernet (copper) ports quantity	1
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP+ module slots quantity	1
Console port	RJ-45
USB 2.0 ports quantity	1
Power connector	DC-in jack

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Full duplex	Yes
Half duplex	Yes
Auto-negotiation	Yes
Broadcast storm control	Yes
Flow control support	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Number of VLANs	256

Specification	Value
DHCP features	DHCP server, DHCP client
Access Control List (ACL)	Yes
Access Control List (ACL) rules	164
IGMP snooping	Yes

Specification	Value
Multicast support	Yes
Multicast MAC address table	512 entries

Specification	Value
Built-in processor	Yes
Processor frequency	800 MHz
Noise level	28.8 dB
Mean time between failures (MTBF)	376434 h

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	180 W

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Heat dissipation	799.5 BTU/h

Specification	Value
Certification	EN 55032:2012+AC:2013/CISPR 32:2012, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010, VCCI-CISPR 32:2016, AS/NZS CISPR 32:2013, GB4943.1-2011; YD/T993-1998; GB/T9254-2008, 47 CFR FCC, ANSI C63.4:2014, ICES-003:2016, ANSI C63.4:2014, CNS 13438

Specification	Value
Harmonized System (HS) code	85176990
