1000) Grey

Model MS510TXPart no. MS510TX-100EUSEAN 10606449120902

53 specifications

Overview

Brand: NETGEAR
Category: Network Switch
Model: MS510TX
Part numbers: MS510TX-100EUS, MS510TX-100NAS, MS510TX-100AJS
EAN / UPC: 10606449120902, 606449120912, 606449120929
Also known as: NETGEAR MS510TX Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Grey

53 specifications in 14 groups

Specification	Value
Switch type	Managed
Switch layer	L2/L3/L4
Quality of Service (QoS) support	Yes
ARP inspection	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP+ module slots quantity	1
Console port	RJ-45
USB 2.0 ports quantity	1

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Broadcast storm control	Yes
VLAN support	Yes
Number of VLANs	256

Specification	Value
DHCP features	DHCP server, DHCP client
Access Control List (ACL)	Yes
Access Control List (ACL) rules	164
IGMP snooping	Yes

Specification	Value
Multicast support	Yes
Multicast MAC address table	512 entries

Specification	Value
Built-in processor	Yes
Processor frequency	800 MHz
Noise level	21 dB
Mean time between failures (MTBF)	1078683 h

Specification	Value
Power over Ethernet (PoE)	No

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Heat dissipation	89.06 BTU/h

Specification	Value
Certification	EN 55032:2012+AC:2013/CISPR 32:2012, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010, VCCI-CISPR 32:2016, AS/NZS CISPR 32:2013, GB4943.1-2011; YD/T993-1998; GB/T9254-2008, 47 CFR FCC, ANSI C63.4:2014, ICES-003:2016, ANSI C63.4:2014, CNS 13438

Specification	Value
Harmonized System (HS) code	85176990
