NETGEAR M6100-24X3 Managed L3 Gigabit Ethernet (10/100/1000) 4U Black, Grey

NETGEAR M6100-24X3 Managed L3 Gigabit Ethernet (10/100/1000) 4U Black, Grey

Model M6100-24X3Part no. XCM8903SX-10000SEAN 606449109054

45 specifications
  • Speed10000 Mbit/s
  • Type4U
  • ColourBlack, Grey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • 10G supportYes
See all specifications

Overview

Speed
10000 Mbit/s
Type
4U
Colour
Black, Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
10G support
Yes
Brand
NETGEAR
Model
M6100-24X3
Part number
XCM8903SX-10000S
EAN / UPC
606449109054, 5415247069676, 8592978048259
Also known as
NETGEAR M6100-24X3 Managed L3 Gigabit Ethernet (10/100/1000) 4U Black, Grey

Specifications

45 specifications in 14 groups

Management features

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportYes
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
SFP+ module slots quantity16

Network

Networking standardsIEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G supportYes
Port mirroringYes
Flow control supportYes
Link aggregationYes
VLAN supportYes
Number of VLANs4000

Data transmission

MAC address table32000 entries
Number of queues7
Jumbo frames supportYes

Security

DHCP featuresDHCP server, DHCP client
Access Control List (ACL)Yes
IGMP snoopingYes
MAC address filteringYes
SSH/SSL supportYes
Security algorithms802.1x RADIUS, HTTPS, SSH, SSL/TLS
Static port securityYes

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMP, RMON, MIB, LLDP, AAA, sFlow, RSPAN
Supported network protocolsiPv4/iPv6

Design

Rack mountingYes
StackableYes
Form factor4U
Product colourBlack, Grey
Housing materialMetal
Number of fans3 fan(s)
SafetyCE, CSA, UL 1950 /cUL IEC 950/EN 60950

Performance

Maximum data transfer rate10000 Mbit/s

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating altitude0 - 3000 m
Non-operating altitude0 - 3000 m

Weight & dimensions

Width432 mm
Depth441.6 mm
Height175.9 mm

Certificates

CertificationCE FCC Part 15 Class A VCCI Class A Class A EN 55022 (CISPR 22) Class A Class A C-Tick EN 50082-1 EN 55024

Logistics data

Harmonized System (HS) code85176990
