NETGEAR M4200-10MG-PoE+ Managed L2/L3

NETGEAR M4200-10MG-PoE+ Managed L2/L3

10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Graphite

Model M4200-10MG-PoE+Part no. GSM4210P-100NESEAN 606449111286

60 specifications
  • Memory1000 MB
  • Noise28.9 dB
  • Type1U
  • Weight2.05 kg
  • ColourGraphite
  • Switch typeManaged
See all specifications

Overview

Memory
1000 MB
Noise
28.9 dB
Type
1U
Weight
2.05 kg
Colour
Graphite
Switch type
Managed
Brand
NETGEAR
Model
M4200-10MG-PoE+
Part numbers
GSM4210P-100NES, GSM4210P-100AJS
EAN / UPC
606449111286, 5057103043989, 606449111279
Also known as
NETGEAR M4200-10MG-PoE+ Managed L2/L3 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) 1U Graphite

Specifications

60 specifications in 13 groups

Management features

Switch typeManaged
Switch layerL2/L3
Quality of Service (QoS) supportYes
ARP inspectionYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
Installed SFP modules quantity0
Installed SFP+ modules quantity0
SFP+ module slots quantity2
Console portUSB
USB 2.0 ports quantity1

Network

Networking standardsIEEE 802.3az
10G supportYes
Cable types supportedCat5e, Cat6e
Port mirroringYes
IP routingYes
Flow control supportYes
Link aggregationYes
Spanning tree protocolYes
VLAN supportYes
Number of VLANs1000

Data transmission

MAC address table16000 entries
Switching capacity90 Gbit/s
Throughput66.9 Mpps
Latency (1 Gbps)2.8 µs
Latency (10 Gbps)0.9 µs
Packet buffer memory16 MB

Security

DHCP featuresDHCP server, DHCP client
Access Control List (ACL)Yes
Access Control List (ACL) rules512
IGMP snoopingYes

Multicast features

Multicast supportYes

Design

Rack mountingYes
StackableYes
Form factor1U
Product colourGraphite
LED indicatorsFan fail, Power

Performance

Processor frequency800 MHz
Memory typeRAM
Internal memory1000 MB
Flash memory256 MB
Noise level28.9 dB

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)240 W
Power consumption (max)281.6 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet plus (PoE+) ports quantity8
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget240 W

Weight & dimensions

Weight2.05 kg

Packaging content

Cables includedAC, LAN (RJ-45), Mini-USB, SFP+, USB
ManualYes
User guideYes

Packaging data

AC adapter includedYes
Mounting brackets includedYes
Resource CDYes
Rubber feetYes
Stackable kitYes
Wall mounting kitYes
