NETGEAR M4100-12GF Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

NETGEAR M4100-12GF Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Model M4100-12GFPart no. GSM7212F-100AJSEAN 606449080919

50 specifications
  • Memory128 MB
  • Noise30 dB
  • Weight3.67 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity12
See all specifications

Overview

Memory
128 MB
Noise
30 dB
Weight
3.67 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
12
Brand
NETGEAR
Model
M4100-12GF
Part number
GSM7212F-100AJS
EAN / UPC
606449080919
Also known as
NETGEAR M4100-12GF Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Specifications

50 specifications in 13 groups

Management features

Switch typeManaged
Switch layerL2+

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity12
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Combo SFP ports quantity12
USB 2.0 ports quantity1

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Port mirroringYes
IP routingYes
Auto MDI/MDI-XYes
Auto-negotiationYes
Flow control supportYes
Link aggregationYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresPrivate VLAN, Voice VLAN, Tagged VLAN, Port-based VLAN
Number of VLANs1024

Data transmission

MAC address table16000 entries
Switching capacity24 Gbit/s
Forwarding rate17.8 Mpps
Store-and-forwardYes
Latency (10-100 Mbps)10.194 µs
Latency (1 Gbps)3.91 µs
Jumbo frames supportYes
Jumbo frames9000
Packet buffer memory1.5 MB

Security

DHCP featuresDHCP server, DHCP relay, DHCP client
IGMP snoopingYes

Protocols

Management protocolsSNMP v1 / v2c / v3

Design

Rack mountingYes
Product colourGrey

Performance

Internal memory128 MB
Flash memory32 MB
Noise level30 dB
Mean time between failures (MTBF)670956 h

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)160.6 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity1
Power over Ethernet plus (PoE+) ports quantity4
Total Power over Ethernet (PoE) budget150 W

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%

Weight & dimensions

Width440 mm
Depth204 mm
Height43 mm
Weight3.67 kg

Certificates

CertificationVCCI Class A
