NETGEAR JGS524Ev2 Managed Gigabit Ethernet (10/100/1000) Grey

NETGEAR JGS524Ev2 Managed Gigabit Ethernet (10/100/1000) Grey

Model JGS524Ev2Part no. JGS524EV2-200EUS

58 specifications
  • Noise0 dB
  • Weight1.4 kg
  • ColourGrey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
See all specifications

Overview

Noise
0 dB
Weight
1.4 kg
Colour
Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
Copper ethernet cabling technology
10BASE-T, 100BASE-T, 1000BASE-T
Brand
NETGEAR
Model
JGS524Ev2
Part number
JGS524EV2-200EUS
Also known as
NETGEAR JGS524Ev2 Managed Gigabit Ethernet (10/100/1000) Grey

Specifications

58 specifications in 13 groups

Management features

Switch typeManaged
Quality of Service (QoS) supportYes
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology10BASE-T, 100BASE-T, 1000BASE-T
Port mirroringYes
Full duplexYes
Broadcast storm controlYes
Flow control supportYes
Link aggregationYes
Rate limitingYes
VLAN supportYes
Virtual LAN featuresTagged VLAN, Port-based VLAN
Number of VLANs100

Data transmission

MAC address table16000 entries
Switching capacity48 Gbit/s
Store-and-forwardYes
Number of trunks16
Jumbo frames supportYes
Jumbo frames9000

Security

DHCP featuresDHCP client
IGMP snoopingYes
DoS attack preventionYes
Loop protectionYes
Password protectionYes
Queue scheduling algorithmsPriority queuing (PQ), Weighted Round Robin (WRR)

Multicast features

Multicast supportYes
Number of multicast groups filtered64

Design

Rack mountingYes
Product colourGrey
LED indicatorsActivity, Link, PoE, Power, Speed, Status
Number of fans0 fan(s)
SafetyCB, CE LVD, CCC, EAC, UL 60950-1
Electromagnetic compatibilityCE, FCC 15, VCCI, RCM, KCC, EAC, CCC

Performance

Buffer size768 KB
Firmware upgradeableYes
Noise level0 dB
Mean time between failures (MTBF)243476 h

Power

Power consumption (max)13.8 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Non-operating altitude0 - 3000 m
Heat dissipation47.2 BTU/h

Weight & dimensions

Width328 mm
Depth170 mm
Height43 mm
Weight1.4 kg

Packaging content

Cables includedAC
Quick start guideYes
Rack mount kitYes
