NETGEAR GS516TP-100NAS network switch Managed L2+/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

NETGEAR GS516TP-100NAS network switch Managed L2+/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Model GS516TP-100NASEAN 606449097481

59 specifications
  • Noise24.6 dB
  • Weight2.21 kg
  • ColourBlack, Grey
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity16
  • 10G supportNo
See all specifications

Overview

Noise
24.6 dB
Weight
2.21 kg
Colour
Black, Grey
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
16
10G support
No
Brand
NETGEAR
Model
GS516TP-100NAS
Part number
GS516TP-100NAS
EAN / UPC
606449097481, 6064490974818
Also known as
NETGEAR GS516TP-100NAS network switch Managed L2+/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black, Grey

Specifications

59 specifications in 15 groups

Management features

Switch typeManaged
Switch layerL2+/L3
Quality of Service (QoS) supportYes
Web-based managementYes
ARP inspectionYes
Traffic classificationYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity16
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroringYes
Full duplexYes
Auto-sensingYes
Broadcast storm controlYes
Flow control supportYes
Link aggregationYes
Rate limitingYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresTagged VLAN
Number of VLANs256

Data transmission

MAC address table8000 entries
Switching capacity32000 Gbit/s
Store-and-forwardYes
Number of queues4
Number of static routes32
Jumbo frames supportYes
Jumbo frames9000

Security

DHCP featuresDHCP client
Access Control List (ACL)Yes
Access Control List (ACL) rules480
IGMP snoopingYes
AuthenticationGuest VLAN, MAC-based authentication, Port-based authentication

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMP V1, V2, V3

Design

Product colourBlack, Grey
LED indicatorsYes
Number of fans1 fan(s)

Performance

Noise level24.6 dB
Mean time between failures (MTBF)479350 h

Power

Power supply includedYes
Power consumption (max)92.1 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity8
Power over Ethernet (PoE) power per port15.4 W
Total Power over Ethernet (PoE) budget76 W

Operational conditions

Operating temperature (T-T)0 - 50 °C
Heat dissipation84 BTU/h

Weight & dimensions

Width328 mm
Depth169 mm
Height43 mm
Weight2.21 kg

Packaging content

Cables includedAC
Rack mount kitYes

Packaging data

Resource CDYes
