GS316 Unmanaged Gigabit Ethernet (10/100/1000) Black
Model GS316Part no. GS316-300EUSEAN 606449164251
43 specifications
- Weight840 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity16
- 10G supportNo
- MAC address table16000 entries
Overview
- Weight
- 840 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 16
- 10G support
- No
- MAC address table
- 16000 entries
- Brand
- NETGEAR
- Category
- Network Switch
- Model
- GS316
- Part numbers
- GS316-300EUS, GS316-100PES, GS316-100UKS
- EAN / UPC
- 606449164251, 606449113136, 6064491131364, 606449113143
- Also known as
- NETGEAR GS316 Unmanaged Gigabit Ethernet (10/100/1000) Black
Specifications
43 specifications in 13 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| 10G support | No |
| Full duplex | Yes |
| Half duplex | Yes |
| Auto MDI/MDI-X | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 16000 entries |
| Switching capacity | 32 Gbit/s |
| Forwarding rate | 1.448 Mpps |
| Latency (1 Gbps) | 3.9 µs |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
| Packet forwarding rate (1 Gbps) | 1448000 pps |
| Packet buffer memory | 0.768 MB |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Activity, Link, Power, Speed |
| On/off switch | No |
Performance
| Specification | Value |
|---|---|
| Buffer size | 768 KB |
| Plug and Play | Yes |
| Mean time between failures (MTBF) | 9041798 h |
Power
| Specification | Value |
|---|---|
| DC input voltage | 12 V |
| Input current | 1 A |
| Input voltage | 12 V |
| Output current | 1 A |
| Power consumption (max) | 8.4 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
| Heat dissipation | 2873 BTU/h |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 286 mm |
| Depth | 101 mm |
| Height | 26 mm |
| Weight | 840 g |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
Certificates
| Specification | Value |
|---|---|
| Certification | CE Mark, FCC Part 15 Class A, IC Class A, RCM, CCC, VCCI, KC |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85176990 |
