NETGEAR GS110MX Unmanaged

NETGEAR GS110MX Unmanaged

10G Ethernet (100/1000/10000) Black

Model GS110MXPart no. GS110MX-100PESEAN 606449128888

45 specifications
  • Weight740 g
  • ColourBlack
  • Switch typeUnmanaged
  • Basic switching RJ-45 Ethernet ports quantity10
  • Networking standardsIEEE 802.1p, IEEE 802.3x
  • MAC address table16000 entries
See all specifications

Overview

Weight
740 g
Colour
Black
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
10
Networking standards
IEEE 802.1p, IEEE 802.3x
MAC address table
16000 entries
Brand
NETGEAR
Model
GS110MX
Part numbers
GS110MX-100PES, GS110MX-100NAS, GS110MX-100UKS
EAN / UPC
606449128888, 606449128871, 606449128864
Also known as
NETGEAR GS110MX Unmanaged 10G Ethernet (100/1000/10000) Black

Specifications

45 specifications in 13 groups

Management features

Switch typeUnmanaged
Quality of Service (QoS) supportYes
MIB supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity10
Basic switching RJ-45 Ethernet ports type10G Ethernet (100/1000/10000)
Gigabit Ethernet (copper) ports quantity8
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Power connectorDC-in jack

Network

Networking standardsIEEE 802.1p, IEEE 802.3x
10G supportYes
Broadcast storm controlYes
Ethernet LAN data rates10,100,1000 Mbit/s
Flow control supportYes
Link aggregationYes
VLAN supportYes

Data transmission

MAC address table16000 entries
Switching capacity56 Gbit/s
Number of trunks8
Static routeYes
Jumbo frames supportYes
Jumbo frames10240

Security

IGMP snoopingYes

Multicast features

Multicast supportYes

Design

Rack mountingYes
Product colourBlack
LED indicatorsYes
SafetyUL 60950-1/CAN/CSA C22.2 No. 60960-1-07 EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013 AS/NZS 60950.1:2015

Power

Power sourceDC
DC input voltage13.2 V
Power consumption (typical)4.8 W
Power consumption (max)6.6 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 3000 m
Heat dissipation45.14 BTU/h

Weight & dimensions

Width236 mm
Depth102 mm
Height27 mm
Weight740 g

Certificates

Certification47 CFR FCC, ICES-003:2016, ANSI C63.4:2014, EN 55032:2012 +AC:2013, CISPR 32:2012, AS/NZS CISPR 32:2013, EN 55032:2015 +AC:2016, CISPR 32:2015 +COR1:2016, AS/NZS CISPR 32:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010 +A1:2015, AS/NZS CISPR 32:2015, VCCI-CISPR 32:2016,

Logistics data

Harmonized System (HS) code85176990
