1000) Power over Ethernet (PoE) 1U White

Model GC728XPPart no. GC728XP-100EUSEAN 606449122886

57 specifications

Overview

Brand: NETGEAR
Category: Network Switch
Model: GC728XP
Part numbers: GC728XP-100EUS, GC728XP-100NAS
EAN / UPC: 606449122886, 606449122718
Also known as: NETGEAR GC728XP Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U White

57 specifications in 16 groups

Specification	Value
Switch type	Managed
Switch layer	L2/L3/L4
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
System event log	Yes

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	2
SFP+ module slots quantity	2
USB 2.0 ports quantity	1
Power connector	DC-in jack

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	No
Number of VLANs	256

Specification	Value
DHCP features	DHCP client
Access Control List (ACL)	Yes
Access Control List (ACL) rules	100

Specification	Value
Multicast support	Yes
Number of multicast groups filtered	512

Specification	Value
Processor frequency	400 MHz
Internal memory	1.5 MB
Noise level	39 dB
Mean time between failures (MTBF)	629962 h

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	24
Total Power over Ethernet (PoE) budget	390 W

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 90%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 3000 m
Heat dissipation	1491.45 BTU/h

Specification	Value
Rubber feet	Yes

Specification	Value
Certification	CE, EN55032:2012+AC:2013, EN55024:2010+A1:2015, EN61000-3-2:2014, EN61000-3-3:2013, VCCI-CISPR 32:2016, RCM, AS/NZS CISPR 32:2015, ICES-003:2016, BSMI CNS13438, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, UL 60950-1, 2nd, 2014 and CAN/CSA C22.2 No. 60950-1-07, 2nd, 2014, IEC 60950-1:

Specification	Value
Harmonized System (HS) code	85176990
