NEC QX-S408E Fast Ethernet (10/100) Grey
Model QX-S408EPart no. B02014-00411EAN 4548835909564
21 specifications
- Weight750 g
- ColourGrey
- Basic switching RJ-45 Ethernet ports quantity8
- Networking standardsIEEE 802.3x
- MAC address table8000 entries
- BPDU filtering/protectionYes
Overview
- Weight
- 750 g
- Colour
- Grey
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Networking standards
- IEEE 802.3x
- MAC address table
- 8000 entries
- BPDU filtering/protection
- Yes
- Brand
- NEC
- Category
- Network Switch
- Model
- QX-S408E
- Part number
- B02014-00411
- EAN / UPC
- 4548835909564
- Also known as
- NEC QX-S408E Fast Ethernet (10/100) Grey
Specifications
21 specifications in 9 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3x |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Switching capacity | 1.6 Gbit/s |
| Packet forwarding rate (1 Gbps) | 1100000 pps |
Security
| Specification | Value |
|---|---|
| BPDU filtering/protection | Yes |
Design
| Specification | Value |
|---|---|
| Product colour | Grey |
Power
| Specification | Value |
|---|---|
| AC input voltage | 100 V |
| Power consumption (typical) | 2.7 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 195 mm |
| Depth | 119 mm |
| Height | 38 mm |
| Weight | 750 g |
Certificates
| Specification | Value |
|---|---|
| Certification | VCCI Class A, RoHS |
