Linksys 28-Port Managed Gigabit Switch (LGS528)

Linksys 28-Port Managed Gigabit Switch (LGS528)

Model LGS528-EUEAN 745883635542

57 specifications
  • Memory128 MB
  • Type1U
  • Weight2.43 kg
  • ColourBlack
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity26
See all specifications

Overview

Memory
128 MB
Type
1U
Weight
2.43 kg
Colour
Black
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
26
Brand
Linksys
Model
LGS528-EU
Part number
LGS528-EU
EAN / UPC
745883635542, 4260184663965
Also known as
Linksys 28-Port Managed Gigabit Switch (LGS528)

Specifications

57 specifications in 13 groups

Management features

Switch typeManaged
Switch layerL2/L3
Quality of Service (QoS) supportYes
Web-based managementYes
System event logYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity26
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity28
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Combo SFP ports quantity2
Fiber optic connectorMiniGBIC

Network

Networking standardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Full duplexYes
Broadcast storm controlYes
Flow control supportYes
Head-of-line (HOL) blockingYes
Link aggregationYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresTagged VLAN
Number of VLANs4096

Data transmission

MAC address table16000 entries
Switching capacity56 Gbit/s
Throughput41.67 Mpps
Number of queues4
Jumbo frames supportYes
Jumbo frames9000

Security

DHCP featuresDHCP client
Access Control List (ACL)Yes
Access Control List (ACL) rules512
IGMP snoopingYes
Security algorithms802.1x RADIUS

Multicast features

Multicast supportYes
Number of multicast groups filtered256

Protocols

Management protocolsHTTP/HTTPS, Telnet, TFTP, PING, SNTP, SNMP v1/ v2c

Design

Rack mountingYes
Form factor1U
Product colourBlack
LED indicatorsActivity, Link, System

Performance

Memory typeDRAM
Internal memory128 MB

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current0.7 A
Power consumption (typical)19.71 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Width440 mm
Depth200 mm
Height44.5 mm
Weight2.43 kg
