Linksys 26-Port Smart PoE+ Switch (LGS326P)

Linksys 26-Port Smart PoE+ Switch (LGS326P)

Model LGS326PPart no. LGS326P-AUEAN 7458836348118

57 specifications
  • Memory128 MB
  • Weight3.1 kg
  • ColourBlack, Blue
  • Switch typeManaged
  • Basic switching RJ-45 Ethernet ports quantity24
  • 10G supportNo
See all specifications

Overview

Memory
128 MB
Weight
3.1 kg
Colour
Black, Blue
Switch type
Managed
Basic switching RJ-45 Ethernet ports quantity
24
10G support
No
Brand
Linksys
Model
LGS326P
Part numbers
LGS326P-AU, LGS326P-EU, LGS326P-UK, LGS326P, LGS326P-EU/KIT1
EAN / UPC
7458836348118, 745883635511, 1122015030052, 4012016030427 +8 more
Also known as
Linksys 26-Port Smart PoE+ Switch (LGS326P)

Specifications

57 specifications in 13 groups

Management features

Switch typeManaged
Quality of Service (QoS) supportYes
Web-based managementYes
System event logYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity26
Installed SFP modules quantity0
Installed SFP+ modules quantity0
Combo SFP ports quantity2

Network

Networking standardsIEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology1000BASE-T, 100BASE-T, 10BASE-T
Port mirroringYes
Broadcast storm controlYes
Flow control supportYes
Head-of-line (HOL) blockingYes
Link aggregationYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresTagged VLAN
Number of VLANs128

Data transmission

MAC address table8000 entries
Switching capacity52 Gbit/s
Throughput38.69 Mpps
Jumbo frames supportYes
Jumbo frames9000

Security

DHCP featuresDHCP client
Access Control List (ACL)Yes
IGMP snoopingYes
MAC address filteringYes
Security algorithms802.1x RADIUS

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMP, IGMP v1/v2/v3, Telnet, DHCP, HTTP/HTTPS

Design

Rack mountingYes
Product colourBlack, Blue
LED indicatorsActivity, Link, PoE, System
Number of fans2 fan(s)

Performance

Memory typeDRAM
Internal memory128 MB
Firmware upgradeableYes

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current3.5 A
Power consumption (typical)28.58 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) ports quantity26
Power over Ethernet plus (PoE+) ports quantity26
Total Power over Ethernet (PoE) budget192 W

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%

Weight & dimensions

Width440 mm
Depth200 mm
Height44 mm
Weight3.1 kg
