LevelOne KIT:GSW-1676 + GSW-1676

LevelOne KIT:GSW-1676 + GSW-1676

Model KIT:GSW-1676 + GSW-1676Part no. 551056/KIT1

48 specifications
  • Speed1 Gbit/s
  • ConnectivityWired
  • Weight1.6 kg
  • ColourGrey
  • Switch typeUnmanaged
  • Basic switching RJ-45 Ethernet ports quantity16
See all specifications

Overview

Speed
1 Gbit/s
Connectivity
Wired
Weight
1.6 kg
Colour
Grey
Switch type
Unmanaged
Basic switching RJ-45 Ethernet ports quantity
16
Brand
LevelOne
Model
KIT:GSW-1676 + GSW-1676
Part number
551056/KIT1
Also known as
LevelOne KIT:GSW-1676 + GSW-1676 Unmanaged L3+ Grey

Specifications

48 specifications in 14 groups

Management features

Switch typeUnmanaged
Switch layerL3+
Quality of Service (QoS) supportYes
Web-based managementYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity16
SFP module slots quantity4
SFP/SFP+ slots quantity4

Network

Networking standardsIEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
Port mirroringYes
Full duplexYes
Auto MDI/MDI-XYes
Broadcast storm controlYes
Flow control supportYes
Rate limitingYes
Number of VLANs255

Optical fiber

Fiber ethernet cabling technology1000BASE‑LX, 1000BASE‑SX

Data transmission

MAC address table8000 entries
Supported data transfer rates10/100 Mbps
Switching capacity32 Gbit/s
Store-and-forwardYes
Number of trunks8
Number of queues4
Maximum data transfer rate1 Gbit/s
Jumbo frames supportYes

Security

DHCP featuresDHCP client
IGMP snoopingYes

Design

StackableNo
Product colourGrey

Performance

Firmware upgradeableYes
Mean time between failures (MTBF)385193 h

Power

Input voltage100 - 240 V
Power consumption (typical)28 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Other features

Dimensions (WxDxH)440 x 171 x 44 mm
Connectivity technologyWired
Input frequency50/60 Hz
Networking featuresGigabit Ethernet
Packet transfer speed400K b
Wi-FiNo
Connectivity LEDsYes

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)5 - 90%
Operating temperature (T-T)32 - 104 °F

Weight & dimensions

Weight1.6 kg

Certificates

CertificationCE, FCC
