IGP-0310 network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Model IGP-0310EAN 4015867226940
40 specifications
- Weight300 g
- ColourBlack
- Basic switching RJ-45 Ethernet ports quantity2
- 10G supportNo
- Packet buffer memory1 MB
- Power over Ethernet (PoE)Yes
Overview
- Weight
- 300 g
- Colour
- Black
- Basic switching RJ-45 Ethernet ports quantity
- 2
- 10G support
- No
- Packet buffer memory
- 1 MB
- Power over Ethernet (PoE)
- Yes
- Brand
- LevelOne
- Category
- Network Switch
- Model
- IGP-0310
- Part number
- IGP-0310
- EAN / UPC
- 4015867226940
- Also known as
- LevelOne IGP-0310 network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Specifications
40 specifications in 12 groups
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 1 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | No |
| Full duplex | Yes |
| Half duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
Data transmission
| Specification | Value |
|---|---|
| Packet buffer memory | 1 MB |
Design
| Specification | Value |
|---|---|
| Rack mounting | No |
| Stackable | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Link |
| International Protection (IP) code | IP30 |
| Wall mountable | Yes |
Power
| Specification | Value |
|---|---|
| Power supply included | No |
| DC input voltage | 12 - 56 V |
| Power consumption (typical) | 5 W |
| Surge protection | Yes |
| Surge protection voltage | 6 kV |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 65 mm |
| Depth | 35 mm |
| Height | 101 mm |
| Weight | 300 g |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package width | 110 mm |
| Package depth | 62 mm |
| Package height | 130 mm |
| Package weight | 350 g |
Certificates
| Specification | Value |
|---|---|
| Certification | CE/FCC |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
