LevelOne 28-Port Modular L2 Managed Fast Ethernet Industrial Switch, 3 x Fast Ethernet Module Slot, 1 x Gigabit Module Slot, -40°C to 85°C
Model IES-2892EAN 4015867181263
62 specifications
- Type1U
- Weight4.5 kg
- ColourBlack
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity24
- 10G supportNo
Overview
- Type
- 1U
- Weight
- 4.5 kg
- Colour
- Black
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 24
- 10G support
- No
- Brand
- LevelOne
- Category
- Network Switch
- Model
- IES-2892
- Part number
- IES-2892
- EAN / UPC
- 4015867181263
- Also known as
- LevelOne 28-Port Modular L2 Managed Fast Ethernet Industrial Switch, 3 x Fast Ethernet Module Slot, 1 x Gigabit Module Slot, -40°C to 85°C
Specifications
62 specifications in 17 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports quantity | 24 |
| Gigabit Ethernet (copper) ports quantity | 4 |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Combo SFP ports quantity | 4 |
| Fiber optic connector | SFP |
| Console port | RS-232 |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-T |
| Port mirroring | Yes |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Flow control support | Yes |
| Rate limiting | Yes |
| Virtual LAN features | Tagged VLAN, Port-based VLAN |
Optical fiber
| Specification | Value |
|---|---|
| Fiber ethernet cabling technology | 1000BASE‑LX, 1000BASE‑SX |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8192 entries |
| Store-and-forward | Yes |
| Packet forwarding rate (1 Gbps) | 1488100 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148810 pps |
| Packet buffer memory | 3 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP server, DHCP client |
| IGMP snooping | Yes |
| MAC address filtering | Yes |
| Static port security | Yes |
Multicast features
| Specification | Value |
|---|---|
| Multicast support | Yes |
Design
| Specification | Value |
|---|---|
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Activity, Link, Power, Status |
| International Protection (IP) code | IP30 |
Performance
| Specification | Value |
|---|---|
| Expansion module support | Yes |
| Mean time between failures (MTBF) | 179348.529 h |
Power
| Specification | Value |
|---|---|
| Power consumption (max) | 42.7 W |
| Power protection features | Overload |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -45 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 442 mm |
| Depth | 343 mm |
| Height | 44.2 mm |
| Weight | 4.5 kg |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
| Resource CD | Yes |
| Package width | 528 mm |
| Package depth | 126 mm |
| Package height | 571 mm |
| Package weight | 6 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | ISO9001 FCC Part 15, Class A EN61000-6-4 EN55022 EN61000-3-2 EN61000-3-3 EN61000-6-2 EN61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5 EN61000-4-6 EN61000-4-8 IEC61000-4-10 IEC61000-4-16 IEC61000-4-18 IEC60870-2-1 IEEE1613 IEC60068-2-6 Fc IEC60068-2-27 Ea IEC60068-2-32 Ed |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
