LevelOne 5-Port Fast Ethernet Industrial Switch, DIN-Rail, 1 x SC Multi-Mode Fiber, -20°C to 70°C
Model IES-0510EAN 846359021668
44 specifications
- Weight200 g
- ColourBlack
- Switch typeUnmanaged
- Basic switching RJ-45 Ethernet ports quantity4
- Copper ethernet cabling technology10BASE-T, 100BASE-TX
- Fiber ethernet cabling technology100BASE-FX
Overview
- Weight
- 200 g
- Colour
- Black
- Switch type
- Unmanaged
- Basic switching RJ-45 Ethernet ports quantity
- 4
- Copper ethernet cabling technology
- 10BASE-T, 100BASE-TX
- Fiber ethernet cabling technology
- 100BASE-FX
- Brand
- LevelOne
- Category
- Network Switch
- Model
- IES-0510
- Part number
- IES-0510
- EAN / UPC
- 846359021668, 4015867181607
- Also known as
- LevelOne 5-Port Fast Ethernet Industrial Switch, DIN-Rail, 1 x SC Multi-Mode Fiber, -20°C to 70°C
Specifications
44 specifications in 15 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Unmanaged |
| Quality of Service (QoS) support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Fiber optic connector | SC |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
Optical fiber
| Specification | Value |
|---|---|
| Fiber ethernet cabling technology | 100BASE-FX |
| Fiber type | Multi-mode |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 2048 entries |
| Store-and-forward | Yes |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (100 Mbps) | 148810 pps |
| Packet buffer memory | 0.384 MB |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Housing material | Plastic |
| LED indicators | Activity, Link, Speed |
| International Protection (IP) code | IP30 |
| Safety | UL60950-1 |
Performance
| Specification | Value |
|---|---|
| Mean time between failures (MTBF) | 1071085 h |
Power
| Specification | Value |
|---|---|
| Input voltage | 12 - 48 V |
| Power consumption (max) | 4.3 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -25 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 26 mm |
| Depth | 70 mm |
| Height | 110 mm |
| Weight | 200 g |
Packaging content
| Specification | Value |
|---|---|
| Quick start guide | Yes |
Packaging data
| Specification | Value |
|---|---|
| Package type | Box |
| Package width | 180 mm |
| Package depth | 79 mm |
| Package height | 221 mm |
| Package weight | 460 g |
Certificates
| Specification | Value |
|---|---|
| Certification | ISO9001 FCC Part 15 EN61000-6-4 EN55022 EN61000-3-2 EN61000-3-3 EN61000-6-2 EN61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5 EN61000-4-6 EN61000-4-8 IEC60068-2-6 Fc IEC60068-2-27 Ea IEC60068-2-32 Ed |
Logistics data
| Specification | Value |
|---|---|
| Country of origin | Taiwan |
| Harmonized System (HS) code | 85176990 |
