1000) Power over Ethernet (PoE) Black

Model GTP-5281EAN 4015867203972

72 specifications

Memory256 MB
Weight6.45 kg
ColourBlack
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity48
10G supportYes

See all specifications

Overview

Memory: 256 MB
Weight: 6.45 kg
Colour: Black
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 48
10G support: Yes

Brand: LevelOne
Category: Network Switch
Model: GTP-5281
Part number: GTP-5281
EAN / UPC: 4015867203972
Also known as: LevelOne GTP-5281 network switch Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Specifications

72 specifications in 16 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
ARP inspection	Yes
System event log	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP+ module slots quantity	2
Console port	RJ-45

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support	Yes
Port mirroring	Yes
Ethernet Ring Protection Switching (ERPS)	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Private VLAN, Voice VLAN, Tagged VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN

Data transmission

Specification	Value
MAC address table	16000 entries
Switching capacity	176 Gbit/s
Forwarding rate	130.94 Mpps
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	10000
Packet buffer memory	1.5 MB

Security

Specification	Value
DHCP features	DHCP snooping
Access Control List (ACL)	Yes
Authentication	Port-based authentication
DoS attack prevention	Yes
SSH/SSL support	Yes
Static port security	Yes

Protocols

Specification	Value
Management protocols	Telnet/SNMP v1/v2/v3
GARP VLAN Registration Protocol (GVRP)	Yes

Design

Specification	Value
Rack mounting	Yes
Stackable	Yes
Product colour	Black
LED indicators	Diagnostic, System, Uplink
Number of fans	4 fan(s)
Safety	CB, UL

Performance

Specification	Value
Physical stacking (units)	4
Memory type	DRAM
Internal memory	256 MB
Flash memory	128 MB
Firmware upgradeable	Yes
Telnet	Yes
Mean time between failures (MTBF)	233125 h

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	65 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	48
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	780 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	440 mm
Depth	391 mm
Height	44 mm
Weight	6.45 kg

Packaging content

Specification	Value
Cables included	AC, LAN (RJ-45)
Rack mount kit	Yes

Packaging data

Specification	Value
Package type	Box
Resource CD	Yes
Rubber feet	Yes
Package width	590 mm
Package depth	505 mm
Package height	133 mm

Certificates

Specification	Value
Certification	FCC Class A, CE, VCCI, WEEE, RoHS

Logistics data

Specification	Value
Country of origin	China
