LevelOne GSW-0841 network switch Managed
Model GSW-0841EAN 4015867130704
35 specifications
- Speed1 Gbit/s
- ConnectivityWired
- Weight1.24 kg
- Switch typeManaged
- Basic switching RJ-45 Ethernet ports quantity8
- 10G supportNo
Overview
- Speed
- 1 Gbit/s
- Connectivity
- Wired
- Weight
- 1.24 kg
- Switch type
- Managed
- Basic switching RJ-45 Ethernet ports quantity
- 8
- 10G support
- No
- Brand
- LevelOne
- Category
- Network Switch
- Model
- GSW-0841
- Part number
- GSW-0841
- EAN / UPC
- 4015867130704
- Also known as
- LevelOne GSW-0841 network switch Managed
Specifications
35 specifications in 12 groups
Management features
| Specification | Value |
|---|---|
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| SFP module slots quantity | 1 |
| SFP/SFP+ slots quantity | 1 |
| Power connector | DC-in jack |
Network
| Specification | Value |
|---|---|
| Networking standards | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | No |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Port mirroring | Yes |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| Broadcast storm control | Yes |
| Flow control support | Yes |
Data transmission
| Specification | Value |
|---|---|
| MAC address table | 8000 entries |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 16 Gbit/s |
| Store-and-forward | Yes |
| Maximum data transfer rate | 1 Gbit/s |
| Jumbo frames support | Yes |
| Packet buffer memory | 0.18 MB |
Security
| Specification | Value |
|---|---|
| DHCP features | DHCP client |
Protocols
| Specification | Value |
|---|---|
| Management protocols | SNMP, TOS, DSCP |
Power
| Specification | Value |
|---|---|
| Power consumption (typical) | 6.24 W |
Power over Ethernet (PoE)
| Specification | Value |
|---|---|
| Power over Ethernet (PoE) | No |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 270 x 187 x 43 mm |
| Connectivity technology | Wired |
| Networking features | Gigabit Ethernet |
| Power requirements | 100 - 240 VAC, 50/60 Hz |
| Connectivity LEDs | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.24 kg |
Certificates
| Specification | Value |
|---|---|
| Certification | CE, FCC Part 15 Class A, VCCI-A |
