LevelOne 50-Port L2 Managed Gigabit Ethernet PoE Switch, 802.3at PoE+

LevelOne 50-Port L2 Managed Gigabit Ethernet PoE Switch, 802.3at PoE+

375W, 2 Ports SFP, 48 PoE Outputs

Model GEP-5070EAN 846359031438

65 specifications

Weight4.05 kg
ColourGrey
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity48
Port mirroringYes
MAC address table32768 entries

See all specifications

Overview

Weight: 4.05 kg
Colour: Grey
Switch type: Managed
Basic switching RJ-45 Ethernet ports quantity: 48
Port mirroring: Yes
MAC address table: 32768 entries

Brand: LevelOne
Category: Network Switch
Model: GEP-5070
Part number: GEP-5070
EAN / UPC: 846359031438, 4015867185094, 8463590314384
Also known as: LevelOne 50-Port L2 Managed Gigabit Ethernet PoE Switch, 802.3at PoE+, 375W, 2 Ports SFP, 48 PoE Outputs

Specifications

65 specifications in 15 groups

Management features

Specification	Value
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Web-based management	Yes
System event log	Yes

Ports & interfaces

Specification	Value
Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	2
Power connector	DC-in jack

Network

Specification	Value
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Port mirroring	Yes
Full duplex	Yes
Flow control support	Yes
Link aggregation	Yes
Rate limiting	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Port-based VLAN

Data transmission

Specification	Value
MAC address table	32768 entries
Switching capacity	100 Gbit/s
Store-and-forward	Yes
Number of trunks	25
Jumbo frames	10000
Packet forwarding rate (1 Gbps)	1488100 pps
Packet forwarding rate (10 Mbps)	14881 pps
Packet forwarding rate (100 Mbps)	148810 pps
Packet buffer memory	0.512 MB

Security

Specification	Value
DHCP features	DHCP client
Access Control List (ACL)	Yes
IGMP snooping	Yes
Auto-edge port	Yes
MAC address filtering	Yes
SSH/SSL support	Yes
Static port security	Yes

Multicast features

Specification	Value
Multicast support	Yes

Design

Specification	Value
Rack mounting	Yes
Product colour	Grey
LED indicators	Activity, Link, PoE, Power

Power

Specification	Value
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	500 W

Power over Ethernet (PoE)

Specification	Value
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	48
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	375 W

Operational conditions

Specification	Value
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%

Weight & dimensions

Specification	Value
Width	440 mm
Depth	350 mm
Height	44.5 mm
Weight	4.05 kg

Packaging content

Specification	Value
Cables included	AC
Quick start guide	Yes
Rack mount kit	Yes

Packaging data

Specification	Value
Mounting brackets included	Yes
Package type	Box
Resource CD	Yes
Package width	535 mm
Package depth	470 mm
Package height	86 mm
Package weight	6.13 kg

Certificates

Specification	Value
Certification	FCC Part 15 Class A, CE, RoHS

Logistics data

Specification	Value
Country of origin	China
